6 Inches Wood Chipper With Hydraulic System For 4 Cutting Knives

FEATURES:

• For 30-150 HP tractors
• Disc-operated chipper, Hydraulic system contains oil tank, hydraulic pump, hoses, oil control valve and control handle
• Hydraulic transmission with double rollers
• Wood feeding control with forward,stop and reverse
• Discharge hood with 360° double adjustment
• Safety kit included
• 4 rotor knives + 1 stationary knife
• Material diameter 6 Inches
• Hydraulic flow speed control valve
• Optional:BX62RF SKF bearings


The Fred BX-62RF is best used with a tractor engine power of 30 to 100 HP. By using the tractor hydraulic system the wood is pulled into the shredder by two spiked rollers making work fast and comfortable. The rollers are guided with ball bearings in both sides for best possible performance. The feed roller control bar is used for operating the hydraulic system in direction (Froward - Stop - Reverse), so that wood jams can be easily solved by switching into “reverse gear”. A high-end hydraulic valve is installed to smoothly adjust the roller speed so that you can adjust the shredder performance to wood type and diameter. Smaller diameter can be shredded faster, than larger diameter.

There are four hardened knives mounted on the 121kg rotor, shredding wood up to 15cm in diameter. The discharge funnel can be turned by 360° with an adjustable throwing angle. The Victory BX-62RF capacity is 16L/min depending on the type of wood.

For easy transportation, the discharge funnel can be lifted up, supported by two shocks. Also the BX-92RF is designed for easy maintenance. The rotor cover can be opened by removing only one screw to get access to the knifes. Because of the very powerful air suction created by the 121kg rotor, wood jams are virtually impossible.

The Fred BX-62RF comes with a PTO shaft with friction clutch for a perfect and safe power transmission from the tractor.
