Heavy Duty 8 Inch Wood Chipper Safety With 7 - 9 Cbm / H Working Capacity
Heavy Duty 8 Inch Wood Chipper Safety With 7 - 9 Cbm / H Working Capacity
Heavy Duty 8 Inch Wood Chipper Safety With 7 - 9 Cbm / H Working Capacity
Heavy Duty 8 Inch Wood Chipper Safety With 7 - 9 Cbm / H Working Capacity
Heavy Duty 8 Inch Wood Chipper Safety With 7 - 9 Cbm / H Working Capacity
Heavy Duty 8 Inch Wood Chipper Safety With 7 - 9 Cbm / H Working Capacity
Specifications
Brand Name :
Fred
Model Number :
WC-8M
Certification :
CE ; ISO
Place of Origin :
Weifang, China
MOQ :
1 Pieces
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :
10000 Pieces Per Year
Delivery Time :
30 Days After Payment
Packaging Details :
Iron Steel Crate Package
Weight :
800lbs.
Flywheel size :
24’’
Qty/20ft :
22 units
Flywheel Weight :
200lbs
Diameter Of Feeding :
8"
Working Capacity :
7 - 9 cbm/h
Description

90° Cutting Angle Wood Chipper Main Shaft Supported By 3 Strong Bearings

Strength in design, CNC plasma cut structural plate steel.

9 hp. min. required.

8” x 8” In-Feed opening

200 lb. 24” Diameter Flywheel (dynamically balanced)

2-Reversible Made in the USA fly wheel knives, 1 bed knife (anvil)

1120 RPM Flywheel speed

NEW Tachometer/ Hour meter (to ensure proper operating speed)

Mechanical gear driven in-feed system.

In-feed rate 58 ft. /min.

Hardened 6.25” dia. chisel type in-feed roller.

Quick hitch Compatible (category 1 quick hitch only).

360 Degree swivel discharge chute.

Adjustable base legs w/ skid shoe type base.

High flow chamber ventilation.

2” diameter main shaft.

3-Heavy duty cast steel main shaft bearings.

Adjustable in-feed roller down pressure.

Weight 800 lbs. (shipping) Steel crate L=46" x W=36" x H=48".

8mm thick steel fly wheel housing.

Easy access fly wheel knife panel.

5 Heavy duty cogged drive belts.

Safety stop bar.

Horizontal “table height” in-feed hopper for easy loading.

Baked on powder coat finish.

Clear vinyl chip baffle.

PTO shaft included (shear bolt protected) .

Colors available; Green , Blue , Yellow, Red, Orange. Color samples available, please request if color shade is a concern.

3 yr. parts warranty.

90% assembled upon delivery.
