dongfeng tuel tanker semir trailer with tractor , 45m3 fuel tanker truck
dongfeng tuel tanker semir trailer with tractor , 45m3 fuel tanker truck
dongfeng tuel tanker semir trailer with tractor , 45m3 fuel tanker truck
dongfeng tuel tanker semir trailer with tractor , 45m3 fuel tanker truck
Specifications
Brand Name :
dongfeng brand
Model Number :
DFD4251
Place of Origin :
CHINA
MOQ :
1
Price :
USD60000-USD75000.00
Supply Ability :
500 Units per month
Delivery Time :
30 working days after received the down payment
Packaging Details :
in nude
Engine :
Cummins L375 30
Displacement :
8900ml
tank volume :
45m3
tank dimension :
11640×φ2210
Description
Drive mode 6×4 　 　
Engine Model Cummins L375 20 　
Max. power(Kw/rpm) 275/2200 　
Max. torque(N.m/rpm) 1400/1300-1500 　
Cylinder bore ×Stroke(mm) 114×145 　
Displacement(ml) 8900 　
Type of fuel Diesel 　
Compression ratio 16.6:1 　
No. of valves 4 　
Cab D310-H1 height ceiling, double berth 　
Capacity 3 persons 　
Gearbox Type Fast 12JS180T 　
Max. torque(N.m) 1800 　
Gear ratio 15.53 12.08 9.39 7.33 5.73 4.46 3.48 2.71 2.10 1.64 1.28 1.00
Clutch Φ430mm pull-type diaphragm spring clutch 　
Frame H×W× T(mm) 300×90×(8+5) 　
Frame width 940 (front ), Frame width 810 ( rear ) 　
No. of spring leaves 3/10 　
Tyre Size 12.00R20 　
Air conditioner A/C 　
Overall size (mm) 12810(L)* 2500(W)*3900 (H)
Wheel base (mm) 7200+1310+1310
Tread (mm) 2040
Kerb mass(Kg) 7000
Min. turning diameter(m) 24
Min. ground clearance 360
Main configuration parameters
Axles BPW12T, Germany, 3 axles
Towing pin JOST, 50mm or 90mm
suspension BPW brand triple air suspension
Trailer tyre 425/65R22.5 radial tire, 6
Brake system dual circuit air brake, Service brake, Parking brake, emergency brake
ABS WABCO made, America
Tank body parameter
Tank actual volume(m3) 45
Tank actual dimension(mm) 11640×φ2210
Tank material carbon steel
Discharge aluminum alloy DN80
Discharge rubber hose 2 set, 4m length, ball valve accord with drift diameter
bottom valve None
Tank mouth Two, aluminum alloy, diameter: Φ500
