1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder
1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder
1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder
1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder
1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder
1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder
1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder
1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder
Specifications
Brand Name :
DF
Model Number :
2.7m
Certification :
ISO
Place of Origin :
China
MOQ :
1 sets
Price :
1200 USD per set
Payment Terms :
T/T
Supply Ability :
5000 sets per year
Delivery Time :
5-8 work days
Packaging Details :
steel box
Type :
Sickle-bar
Working range :
2.7m
Cutting height :
50-60 mm
Description

1.4m to 4.2m sickle-bar mower suit for 15hp to 150hp tractors, with hydraulic cylinder

Rear suspension reciprocating mower

The mower drives by the tractor power output shaft.

The movement or start-stop of the mower cutter is controlled by the tractor's PTO or clutch.

The mower is mounted on the three-point suspension mechanism at the rear of the tractor, and the mechanism controls the landing.

The working angle of the mower is controlled by the cylinder.

This lawn mower is suitable for agriculture, forestry and pastoral areas, flat pastures and sloping fields, hilly land and other different grasslands for harvesting natural pastures and planting pastures, alfalfa and reeds.

1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder

The 9G series of Sickle-Bar Mower takes advantage of offset crank link mechanism to drive the cutter blade mow grass, wheat, oats, reed and other herbs. It is suitable for cutting the natural and planted grasses in ranch, mountain and hilly area. The machine is compact in structure, simple and reliable in operation, and has less residue after cutting.

Model 9GC-1.4 9GC-1.6 9GC-1.8 9GC-2.1
Cutting width (mm) 1400 1600 1800 2100
Cutting Height (mm) 50-80
PTO speed (rpm) 540
Weight (kg) 120 125 130 135
Tractor Power (hp) 12-20 15-20 20-30 20-30
Mounted Cat 3 point linkage, CAT I

1.4m To 4.2m Sickle Bar Mower For 15hp To 150hp Tractors With Hydraulic Cylinder

For more info, please contact me.
