20 feet skeleton container semi-trailer
Container skeleton semi-trailers are also known as 20-foot skeleton semi-trailers, container chassis trailers and so on. They are generally used in ports, shipyards, shipping companies, bridges, tunnels, transfer stations, and to support the International Organization for Standardization of Container Transportation's multimodal logistics system. It is suitable for container locking of dry cargo containers, containers, reefer containers and so on.
Type | Semi-Trailer |
Material | Steel |
Use | Truck Trailer |
Place of Origin | Shandong |
Product name | Skeleton container semi-trailer |
Alxe | 2/3/4 axle FUWA Brand |
Suspension | Mechanical Suspension,Air Suspension |
Tyres | 12R22.5 |
Tire number | 12 |
Landing Gear | 28t Heavy Duty Landing Gear |
King pin | 2”(50mm)or3.5”(90mm)JOST |
Front overhang radius | 5800mm |
Wheelbase | 5200+1300+1300mm |
Payload | 32000kg |
Overall mass | 40000kg |
Saddle load | 16000kg |
Saddle height | 1600mm |
Processing Customisation | Yes |
Overall dimensions | 8000*2550*1350mm |
Speed | 100km/h |
Height of traction surface | 200mm |
Thickness of traction neck | 290mm |
color | optional |
PACKING AND SHIPPING
We find the best shipping solution according to the actual order size to reduce the transportation cost and save the transportation cost for customers Common shipping: bulk carrier, ro-ro ship,container ship, frame ship
(1) Waxing: carry out wax spraying treatment
(2) Packing: stabilized and fixed with steel wire to protect the trailer during transportation.
(3) Transportation: Reliable logistics services from well-known freight forwarding providers to make the transportation process safe and timely.
(4) In 80% of the cases, we can provide customers with 15-20 days delivery for regular trailers.
(5) We can ship all trucks and trailers and spare parts by all means of transportation.
(6) For 90% of our cargoes, we will ship by sea, by container or roll-on/roll-off/bulk/flatbed to all major continents, such as South America, the Middle East, Africa, Oceania, etc. We can also ship by road or by road to the neighboring countries of China, such as Russia, Tajikistan, Kazakhstan and Mongolia.
(7) For China's neighboring countries, such as Russia, Tajikistan, Kazakhstan, Mongolia, etc., we can ship by road or railroad transportation trucks.
(8) For light spare parts for urgent needs, we can ship them by international courier services, such as DHL, TNT, UPS or Fedex.
