Specifications
Brand Name :
CIMC
Model Number :
SINOMTP02010
Certification :
BV,SGS, CNCA, CIQ
Place of Origin :
China
MOQ :
1
Price :
$14000-$25000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 units / per month
Delivery Time :
2-3 weeks
Packaging Details :
Nude, but with wax sprayed
Product Name:: :
dump semitrailer
axle :
3 axle
Capacity: :
50 Tons
Materials: :
Carbon Steel / High Strength Steel
Transport:: :
Sand, Stone, Mental, Coal, Etc
Lifting System: :
Hydraulic Cylinder
Description

Specification:

Tare Weight 10.5T
volume 36m3
Pay-load 50T
Wheel Base 1310 (mm)
Tyre 385/ 12R 22.5 / 11.00R 20
Tyre quantity 6 /12 +1 spare
Axle brand FUWA/ BPW optional
Axle 3
Axle-load 13 Ton
Hydraulic Hyva
King Pin 50# 90# changeable
Landing Leg 28ton JOST
Suspension Air Suspension: Wabco
Front/Rear Overhang 1950 mm
Outside Dimensions (LxWxH) 10X2.5X3.7M
Material of the Main Beam T700 high tensile steel, yield strength: 800MPA.
Side 4mm, Bottom 6mm
Brake System Dual line braking system With Automatic Air Chambers
Brake Air Chamber Wabco
Electrical 24V, 7core socket, lights according to European standards.
Color Any color will be available
Accessory One tooling box with a set of standard trailer tool
Spare tire carrier 1 set


Description:

1, Made by high tensile strength steel, Q345B, Q610, 700
2, heave duty loading capacity. Dump volume: 25M3-55M3.
3, square shape or U-shape design, nice appearance.
Applications:
3 axle Dump trailers can take different Materials including (in many sizes, types, grades and colors):

  • Crush Stone
  • Rock
  • Sand / Sandy Loam
  • Gravel
  • Masonry Aggregates
  • Mulch
  • Recycled Products
  • Fill Dirt
  • Fill Materials
  • Specialty Aggregates
  • Base Rock
  • Topsoil
  • Custom Soils Mixes
  • Clay and Construction Materials
  • Landscape Materials
  • Asphalt
  • Oil Field Materials
  • Dump Sites for Dirt, Concrete, Asphalt, Rubble, Dredge and Contaminated Materiales

Competitive Advantage:
1. Well-known brand axles, suspension systems, high performance, and reliable to use, to ensure the good performance of the vehicle.
2. Full braking and electrical systems at home and abroad in accordance with ISO standard, optional ABS system, braking, lighting is absolutely safe and reliable.
3. Frame overall spray primer treatment, paint spraying fine surface quality of maritime anti-corrosion standards.
