2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder
2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder
2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder
2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder
2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder
2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder
2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder
2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder
Specifications
Brand Name :
HAIZHOU
Model Number :
HZ4257N3247
Certification :
ISO/CCC/SGS
Place of Origin :
China
MOQ :
1pcs
Price :
$9000-20000
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Nude
Product Name :
Semi trailer
Payload :
30-50TONS
Application :
Equipment And Bulk Cargo Transportation
Axles No. :
2 Axles
Material :
High Strength Steel Material
advantage :
Customized Design
Standard :
ISO/CCC/SGS
color :
Optional
Description

Double axles Low Bed Trailers in yellow color with hydraulic ladder and fuwa axles with warranty
Specification:

Low bed semi-trailer 2axles
Overall DimensionLength(mm)13000
Width(mm)3000
Height(mm)2650
Tare Weight(kg)8100
Payload(kg)26000
Quantity of Axle2
Wheelbase(mm)9150+1230
Wheel Track(mm)-/2160/2160
Rear Overhang(mm)1670
Departure Angle(°)16
Leaf Spring-/8/8
Tyre8.25R20
Quantity of Tyre8
II. STANDARD SPECIFICATION
NO.ProductsTechnical Specification, Brand, etc
1Main Frame16Mn steel, Opting for the most advanced digital control plasma cutting technique, welded by automatic Submerged-Arc processes Beam Height: 500mm , Upper Flange thickness: 16mm; Under Flange thickness: 16mm;Ventral Flange thickness: 10mm
2Axle13ton STR axles
3Pneumatic Braking SystemSEALCO brand
4Air Chamber2 pcs double type ,2 pcs single type
5SuspensionWONDEE brand
6Leaf Spring8 leaves
7Kingpin2" welding type
8Electrical System24V
9Wheel Rimwheel rim 8.0-20
10Tyre8.25-2016PR, 8pcs
11Mud GuardReinforce Plastic Mud Guard
12Tool Boxwithout
13Flexible Side GuardrailOptional


Description:
1. Well-known brand axles, suspension systems, high performance, and reliable to use, to ensure the good performance of the vehicle.
2. Frame overall spray primer treatment, paint spraying fine surface quality of maritime anti-corrosion standards.
Applications:
Apply to transport longer larger parts, miscellaneous pieces of cargo, large components and equipment.
Competitive Advantage:
1. Frame body Q345B high strength structure steel, automatic submerged arc welding throughout beams, and other cross-section main stringers structure for optimum carrying effect.
2. Innovative design, tailored to local transport environment analysis on the basis of full understanding of, learn from the advanced design concept, many innovative.
3. Full braking and electrical systems at home and abroad in accordance with ISO standard, optional ABS system, braking, lighting is absolutely safe and reliable.
Warranty

ITEM NAMEWARRANTYITEM NAMEWARRANTY
MAIN FRAMEFRAME1 YEARRUNNING GEARAXLE6 MONTHS
SUSPENSION6 MONTHSAXLE BEARING3 MONTHS
KING PIN1 YEARWHEEL HUB3 MONTHS
BALANCE ARM3 MONTHSTIRE6 MONTHS
ITEM NAMEWARRANTYITEM NAMEWARRANTY
BRAKING DEVICEBRAKE DRUM3 MONTHS

SUPPORT
DEVICE

LANDING GEAR6 MONTHS
BRKE CHAMBER3 MONTHSSPARE WHEEL CARRIER6 MONTHS
AIR RESERVOIR6 MONTHS
ITEM NAMEWARRANTY
OTHERSLEAF SPRING3 MONTHS
BRAKE CHAMBER DIAPHRAGM3 MONTHS
EMERGENCY RELAY VALVE3 MONTHS
BRAKE SHOE3 MONTHS
RELAY VALVE3 MONTHS

2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder2 Axle Lowboy Trailer Gooseneck Low Bed Trailer With Hydraulic Ladder
