Dual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel Versatile
Dual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel Versatile
Dual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel Versatile
Dual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel Versatile
Dual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel Versatile
Dual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel Versatile
Dual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel Versatile
Dual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel Versatile
Specifications
Brand Name :
HAIZHOU
Model Number :
HZ4257N3247
Certification :
ISO/CCC/SGS
Place of Origin :
China
MOQ :
1pcs
Price :
$9000-16000
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Nude
Product Name :
Flat Bed Semi trailer
Payload :
40 TONS
Application :
Carrying 40ft Container, 20 Ft Containers, Hose, Steel Plate, Cement Bags
Axles No. :
3 Axles
Material :
High Strength Steel Material
advantage :
Customized Design
Standard :
ISO/CCC/SGS
color :
Optional
Dimensions :
20 0r 40 Ft Flatbed Trailer Or Customized Available
Description

Dual Axles 20 foot extendable flatbed trailer / semi truck flatbed Trailer with warranty

Specification:

DIMENSION

12450mm*2490mm*1700mm,Size can be design depends

on customers’ request
AXLES/SUSPENSION Boige suspension, 32 Ton
RIM 9.00-22.5 9PCS or other sizes
TIRE 12R22.5-22.5 9 PCS or other sizes ,Triangle/Double Coin/Linglong
KINGPIN JOST brand 2.0 or 3.5inch bolts type
LANDING LEG JOST brand C200T or China brand 28Tons (Double speed)
MAIN BEAM

Height: 450mm-520mm, upper plate is 14mm-16mm,

middle plate is 8mm-12mm,

down plate is 16mm-20mm ; Material is Q345B standard steel .
SIDE BEAM 16mm -25mm channel steel (Material is Q235B standard steel ).
PLATFORM Standard 3 mm thickness checkered plate
BRAKING SYSTEM

WABCO brand emergency valve, T30/30+T30 Spring

brake chamber, one piece of 45L air tank , ABS is optional
TWIST LOCKS 4 or 8 or 12PCS (lift and screw type for choose)
ELECTRIC SYSTEM Voltage is 24V / 7 ways (7 wire harness) / LED light
TOOL BOX

One piece ,equipped with 1 unit Tire spanner,1 piece sleeve

and 1 piece cranking bar)
PAINTING

Complete Chassis sand blasting to clean rust, 1 coat of anti

corrosive prime, 2 coats of final paint

Description:

HAIZHOU manufactures high quality Flatbed Semi Trailer. With the technical expertise of our professionals, we are capable to provide Flatbed Semi Trailer which has various applications and multiple functions, SINOMTP Flatbed Semi Trailer can be usage for 40 ft containers. For the complete satisfaction of the clients, we manufacture is as per their requirements and demands. The long lasting life and low maintenance of Flatbed Semi Trailer is appreciated among the clients.

Applications:
SINOMTP Flate bed semi trailer is mainly used to Carry 40ft Container, 20 Ft Containers, Hose, Steel Plate, Cement Bags ..Our flat bed semi trailer are engineered and custom built to meet the
needs of each customer, based on application, regional weight laws, severity of service, operational efficiency and personal preferences.
Flatbed semi trailers are another commonly used type of equipment in the transportation industry.
Flatbed trailers are used to deliver products like pipe, steel, lumber, heavy equipment, and any other Itemthat would be difficult to load into the back of a trailer. Flatbeds are more versatile than dry vans,because they can be loaded from anywhere on the trailer.

Competitive Advantage
1, Strong trailer frame was made from T700 steel
2, The floor is covered with corrugated sheet metal
3, Heavy duty type suspension
4, Good brake effects. Axles are equipped with WABCO emergency brake valve also dual-brake chamb- ers also widen brake pads

Warranty

ITEM NAME WARRANTY ITEM NAME WARRANTY
MAIN FRAME FRAME 1 YEAR RUNNING GEAR AXLE 6 MONTHS
SUSPENSION 6 MONTHS AXLE BEARING 3 MONTHS
KING PIN 1 YEAR WHEEL HUB 3 MONTHS
BALANCE ARM 3 MONTHS TIRE 6 MONTHS
ITEM NAME WARRANTY ITEM NAME WARRANTY
BRAKING DEVICE BRAKE DRUM 3 MONTHS SUPPORT DEVICE LANDING GEAR 6 MONTHS
BRKE CHAMBER 3 MONTHS SPARE WHEEL CARRIER 6 MONTHS
AIR RESERVOIR 6 MONTHS
ITEM NAME WARRANTY
OTHERS LEAF SPRING 3 MONTHS
BRAKE CHAMBER DIAPHRAGM 3 MONTHS
EMERGENCY RELAY VALVE 3 MONTHS
BRAKE SHOE 3 MONTHS
RELAY VALVE 3 MONTHS

Dual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel VersatileDual Axles 20 Foot Extendable Flat Bed Semi Trailer T700 Steel Versatile
