Double Axles Flat Bed Semi Trailer With Dual Line Braking System For Transport
Double Axles Flat Bed Semi Trailer With Dual Line Braking System For Transport
Double Axles Flat Bed Semi Trailer With Dual Line Braking System For Transport
Double Axles Flat Bed Semi Trailer With Dual Line Braking System For Transport
Double Axles Flat Bed Semi Trailer With Dual Line Braking System For Transport
Double Axles Flat Bed Semi Trailer With Dual Line Braking System For Transport
Specifications
Brand Name :
HAIZHOU
Model Number :
HZ4257N3247
Certification :
ISO/CCC/SGS
Place of Origin :
China
MOQ :
1pcs
Price :
$9000-16000
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Nude
Product Name :
Flat Bed Semi trailer
Payload :
40 TONS
Application :
Carrying 40ft Container, 20 Ft Containers, Hose, Steel Plate, Cement Bags
Axles No. :
3 Axles
Material :
High Strength Steel Material
advantage :
Customized Design
Standard :
ISO/CCC/SGS
color :
Optional
Dimensions :
20 0r 40 Ft Flatbed Trailer Or Customized Available
Description

double axles 12R22 5 tyre flatbed container trailer with abs for ghana with warranty

Specification:

Trailer Model 2 Axle flatbed Container Semi Trailer
Function Carry 1*20ft container or other stuff
Overall Dimension
(Lx W x H)(mm)		 12000*2500*1650
Tare Weight(KG) 6350
Loading Weight( KG) 40000
Total Weight(KG) 50000
Axle Brand 13 TON Axle FUWA Brand
Axle Number two
Wheelbase(mm) 7450+1310
Suspension system Common Mechanical Suspension
Steel Spring 10/10/10 leaf spring suspension
The material of Main beam The height of the beam is 500 mm, upper plate is14mm,
down plate is 16mm, middle plate is 8mm.
Platform plate 3mm Diamond plate
Container Twist Locker 12 pcs container lock
Tire Type and quantity 12R22.5 8 units
Traction Pin 50MM or 90MM
Spare Wheel Bracket 2 pieces
Tool Box 1 Standard
Landing Gear 28 ton
Brake system Dual Line braking system, none ABS
Brake air chamber Two double and two single chamber
Electrical system 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)
Tail lamp with turn signal, brake light & reflector, side lamp etc.
One set 6-core standard Cable.
Side Guard According to customer’s requirement
Painting Color as customer’s requirement
Package NUDE, Polish with wax before shipping
Delivery way Transfer to Qingdao Port, and carry by ro-ro ship,
the freight cost depends on the volume.

Description:

HAIZHOU manufactures high quality Flatbed Semi Trailer. With the technical expertise of our professionals, we are capable to provide Flatbed Semi Trailer which has various applications and multiple functions, SINOMTP Flatbed Semi Trailer can be usage for 40 ft containers. For the complete satisfaction of the clients, we manufacture is as per their requirements and demands. The long lasting life and low maintenance of Flatbed Semi Trailer is appreciated among the clients.

Applications:

Flatbed semi trailers are another commonly used type of equipment in the transportation industry.
Flatbed trailers are used to deliver products like pipe, steel, lumber, heavy equipment, and any other Itemthat would be difficult to load into the back of a trailer. Flatbeds are more versatile than dry vans,because they can be loaded from anywhere on the trailer.

Competitive Advantage
1, Flatbed Semi Trailer can use it to carry one 40 ft cargo container, two 20 ft containers , or one 20 ft container at one time.
2, Flatbed Semi Trailer includes a 3 mm thickness flat platform that is made of checkered plates. Ridges flatbed create more friction, thus making it slip-resistant.
3, All the parts of Flatbed Semi Trailer are purchased from our qualified suppliers, That made Flatbed Semi Trailer more reliable, exhibiting great strength and a long time time of use


Warranty

ITEM NAME WARRANTY ITEM NAME WARRANTY
MAIN FRAME FRAME 1 YEAR RUNNING GEAR AXLE 6 MONTHS
SUSPENSION 6 MONTHS AXLE BEARING 3 MONTHS
KING PIN 1 YEAR WHEEL HUB 3 MONTHS
BALANCE ARM 3 MONTHS TIRE 6 MONTHS
ITEM NAME WARRANTY ITEM NAME WARRANTY
BRAKING DEVICE BRAKE DRUM 3 MONTHS SUPPORT DEVICE LANDING GEAR 6 MONTHS
BRKE CHAMBER 3 MONTHS SPARE WHEEL CARRIER 6 MONTHS
AIR RESERVOIR 6 MONTHS
ITEM NAME WARRANTY
OTHERS LEAF SPRING 3 MONTHS
BRAKE CHAMBER DIAPHRAGM 3 MONTHS
EMERGENCY RELAY VALVE 3 MONTHS
BRAKE SHOE 3 MONTHS
RELAY VALVE 3 MONTHS
