Specifications
Brand Name :
XCMG
Model Number :
QY25K
Certification :
ISO/CCC/SGS
Place of Origin :
China
MOQ :
1pcs
Price :
$10000-50000
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Nude
Product Name :
Truck Crane
Application :
Construction Industry
Rated Lifting Moment :
1010kN.m
Model :
QY
Max. Lifting Load(tons) :
6-16
Emission Standard :
EURO 2
Standard :
ISO/CCC/SGS
Warranty :
12 months
Boom type :
Hydraulic 4 Section Telescopic Boom
Description

high capacity used in construction 7 ton truckcranes for sale

Product Description

Sepcification of our truck crane

Maximum lifting load : 6-16 Ton
Maximum lifting height: 18m-30m
Chassis brand can be choose:Dongfeng/Tking/BMC/Fengsun/Foton or Customized
Emission standard: Euro III or Euro IV , as your requirement

Technical Data

Item name 6 ton 8 ton 10 ton 12 ton 16 ton
Announced chassis TKING/BMC TKING/BMC TKING/BMC TKING/BMC TKING/BMC
Overall dimension(MM) 9454*2140*2980 10100*2180*3140 9700*2300*3180 9970*2340*3180 10100*2420*3230
Max.loading capacity(kg) 6000 8000 10000 12000 16000
Max.lifting height(m) 24 28 30 30 30m
Outrigger system Full hydraulic automatic vertical and horizontal cylinder telescopic H outrigger
Braking form Break air brake form
Steering form Hydraulic power steering form
Crane jib structure 4 or 5section octagonal arm, oil cylinder arm out
Boom type Straight arm,telecopic boom,U-shape
Main Lifting Mechanism Category two planet wheel with a brake inside
Auxiliary Lifting Mechanism Category one gear brake motor
Swing Bearing Internal gear turntable made of 50 manganese steel
Vertical hydraulic leg Double-acting engineering oil cylinder
Horizontal hydraulic leg Double-acting engineering oil cylinder
Platform Anti-skidding and big
Protective Screening Two-way
Night light 3 lamps control
Crane Cab Compeletely digital design,luxury driving cab
The central axially symmetrical Four oil ways
Crane Start Tailor-made
Throttle Hydraulic
Pressure gage and switch Shockproof component
Power takeoff Driving indoor operation
Hydraulic Oil Tank Turntable rearmounted, counter weight combined type, special four-layer filters
Max .gradeability 40%
Ration angle 360°
Arm elevation 90°
Service
1. All the machines will be full tested before shipment; All products have one year warranty and lifetime maintenance serive (collect maintenance after one year)
2. 24 Hours technical support, email, telephone or video online
3. User-friendly english manual for machine using and maintaining
4.Several sets wearing parts will be free for you.
