10 tons Mini Articulated Dump Truck 6x4 for transportation in city road
10 tons Mini Articulated Dump Truck 6x4 for transportation in city road
10 tons Mini Articulated Dump Truck 6x4 for transportation in city road
10 tons Mini Articulated Dump Truck 6x4 for transportation in city road
10 tons Mini Articulated Dump Truck 6x4 for transportation in city road
10 tons Mini Articulated Dump Truck 6x4 for transportation in city road
10 tons Mini Articulated Dump Truck 6x4 for transportation in city road
10 tons Mini Articulated Dump Truck 6x4 for transportation in city road
Specifications
Brand Name :
SINOTRUK HOWO
Model Number :
ZZ3257N2948
Certification :
ISO/CCC
Place of Origin :
China
MOQ :
1set
Price :
USD45000-50000/set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200sets/month
Delivery Time :
20-30 work days after receiving deposite
Packaging Details :
Nude, but with wax sprayed
Product Name :
Dump Truck
Condition :
New
Color :
Optional
Drive type :
6x4
Engine power :
336hp
Cambin :
HW70 cab
Cargo body(CBM) :
16.56
Application :
transportation with dumping function
Description

Specifications:

Cargo body dimension:(mm)

4800*2300*1500,

Bottom8,Side 6,

Strengthened T type

(Carbo body can be customized)
Dimension(Lx W xH)(unloaded) 7356×2496×3170
Approaching angle/Departure angle(°) 19/23
Overhang(front/rear) (mm) 1500/1870
Wheel base (mm) 2900+1350
Max speed(km/h) 75
Curb weight(kg) 12010

Engine

(Steyr technology, made in China)

 Model WD615.69,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and intercooling, directly injection
Fuel type Diesel
Power, max(kw/rpm) 247/2200
Emission EURO Ⅱ (Eu-III available)
Fuel tanker capacity (L) 300
Transmission Model HW15710,10 forward&2 reverse

Brake system

 Service brake Dual circuit compressed air brake
Parking brake spring energy, compressed air operating on rear wheels

Steering system

 Model ZF8098
Front axle HF9
Rear axle HC16
Tyre 12.00R20

Electrical system

 Battery 2X12V/165Ah
Alternator 28V-1500kw
Starter 7.5Kw/24V

Cab

 HOWO70 cab(bed,A/C),all-steel forward control,55º hydraulically tillable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers.

Description:

1. Sinotruk dump truck adopt many key technologies both from home and abroad, and it can achieve the best design and be in good conditions.

2. Low oil consumption. Sinotruk adopt the engine that combine the MAN and steyr technolgoy, it has the perfect oil performance.

3. Sufficient stocked spare parts are available for you when you need to repair your dump truck

4. with the same conditions, our dump truck can be used for a longer time as we used many world famous brand spare parts and assembly.

Applications:

It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials.

Competitive Advantage

1. Sinotruk dump truck adopt many key technologies both from home and abroad,and it can achieve the best design and be in good conditions.

2. Humanization.easy and convenient to drive,there are many key close to touch,and it save human labors and also can make the drive focus on the driving

3. Low oil consumption.Sinotruk adopt the engine that combin the MAN and steyr technolgoy,it has the perfect oil performance.

4. Load more.with using our truck,it can load more goods in safe.

10 tons Mini Articulated Dump Truck 6x4 for transportation in city road10 tons Mini Articulated Dump Truck 6x4 for transportation in city road
