Specifications
Brand Name :
SINOTRUK HOWO
Model Number :
ZZ1047D3415D1
Certification :
ISO/CCC/BV
Place of Origin :
China
MOQ :
1set
Price :
USD20000-50000/set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500sets/month
Delivery Time :
20days after receiving deposite
Packaging Details :
packaing suitable for sea transport
Product Name :
Refrigerator Truck
Application :
Tansport frozen and fresh cargo
Drive :
4x2
Refrigerating capacity :
1.5ton
Min. temperature(°C) :
-18
Color :
optional
Description

Small Refrigerated Box Truck 24v 2 tons with FRP Insulation Panels , -18°C Cargo Van Truck

Specifications:

Item Unit Parameter
Product name Refrigerator Truck
Chassis model ZZ1047D3415D1
Overall dimensions mm 6120,5995×2180×2930
Gross weight kg 4495
Curb weight 2810
Payload capacity 1490
Axle load 1790/2705
Box Van dimensions mm 4110×1930×1755
Wheelbase 3360
Front/Rear track base 1825/1540,1595
Front/Rear overhang 1160/1600,1160/1475
Approach/Departure angle ° 20/23
Exhaust/Power ml/hp 3298/102
Max speed km/h 90
Engine model YN33CRD2 Electric system 24V
Traction system 4×2 Number of axles 2
Tire specifications

7.50-16LT 6PR,7.50R16LT 6PR,

8.25-16LT 6PR,8.25R16LT 6PR,

7.00R16LT 8PR

 Number of tires 6
Operation control system Electrically hydraulic control Allowable passengers in cab 3
Engine diesel engine
Production cycle 7-10 days
warranty 12 month,from the date of supply

Refrigerated Box Truck With Frp Insulation Panels , Refrigerated Truck LoadsRefrigerated Box Truck With Frp Insulation Panels , Refrigerated Truck Loads

Description:

Equipment: chassis, the heat preservation box body,standard material is glass fiber reinforced plastic,

8mm polyurethane insulation layer, Standard back open door and refrigeration unit;
Optional: polyurethane material, color steel plate, stainless steel, etc, 5mm insulation layer, side open

door;
Function: transport frozen foods (ice truck), dairy (milk truck) fruits and vegetables (fresh transporter)

vaccine and drug transporter (vaccine truck), etc

Applications:

Refrigerator truck is closed van truck, which is used to transport frozen or fresh goods, it fitted with the

refrigeration unit device and polyurethane thermal insulation van and it is refrigeration special use

transport truck, usually use for transporting frozen foods (freezer truck), dairy (milk truck), vegetables

and fruits (fresh goods transport vehicle), vaccine and drug (vaccine vehicles) etc…

Competitive Advantage:

Our professional

China Sinotruk special vehicle manufacturers, complete production qualification, such as ISO, CCC,

complete export qualifications such as, special car import and export license.

Our service

Instructions for use in English or in French.Some countries have engine after-sales service station. Have

special requirements, can arrange technicians abroad to after-sales maintenance services.

Our client

we have 8 years experience to serve over 20 countries for exporting different special vehicles.Our special vehicles involved in widespread industry.

Need more information and pictures, please directly contact with me, and we will provide the best service

for you!
