Specifications
Brand Name :
Tractor Truck6x4 420 hp prime mover truck , howo tractor truck Standard Cabin
Model Number :
ZZ4257V3247N1B
Certification :
ISO/CCC/SGS
Place of Origin :
China
MOQ :
1pcs
Price :
$30000-50000
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Nude
Product Name :
Tractor Truck
Traction Capacity :
70-100TONS
Drive Type :
LHD 6X4
Model :
ZZ4257S3241W
Engine :
371HP
Emission Standard :
EURO 2
Standard :
ISO/CCC/SGS
Fifth Wheel :
#50, #90
Description

10 wheels Sinotruk howo 371hp prime mover truck LHD or RHD commercial tractor truck head

Specifications:

Truck Model ZZ4257V3247
Type of Vehicle TRACTOR TRUCK
Truck Brand SINOTRUK -- HOWO
Driving Position Left hand Driving
Fuel tanker capacity(L) 400
The Total Mass 50,000 kg
Dead Weight 8800 kg
Max speed(km/h) 102
Color Optional
Chassis & Add Components
Frame Details High-Strength U-profile ladder frame with section of 300*90*8mm and reinforced sudfram, all cold riveted cross members.
Dimension(L * W * H) (unloaded) (mm) 6800x2496x3800
Approaching angle / Departure angle (°) 16/70
Overhang (front / rear) (mm) 1500/725
Wheel base (mm) 3225+1350
Engine
Model D12.42
Power 420hp/309kw.2000r/min
Emission EURO II
Cylinder bore*stroke (mm) 126*155
Displacement(L) 11.596
Type water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection
Kind of Fuel Diesel
Fuel Consumption(L/100km) 30L/100km
Clutch & Gear Box System
Clutch SINOTRUKΦ430mm diaphragm spring clutch
Gear Box FULLER 12 speeds
Axles
Front Axle Model HF7 axle. Capacity: 7000kg
Rear Axle ST axle. Capacity: 2X 16000kg
Ratio of rear axle 4.42
Electrical System
Battery 2X12V/165Ah
Alternator 28V-1500kw
Starter 7.5Kw/24V
Brake System
Service brake Dual circuit compressed air brake
Parking brake spring energy, compressed air operating on rear wheels
Auxiliary brake Engine exhaust brake
Steering system
Model ZF8098
Type hydraulic steering with power assistance
Wheels & Tyres
Type 12R22.5
Material Tubeless tires
Quantity 10+1 spare
Kin pin 50mm
Cabin
Type HW79 Cabin
double sleeper with air conditioner, all-steel forward control,55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers


Description:
Our company are located in Jinan, that engaged in developing and manufacturing special truck and components, the modern professional enterprise is a public announcement management company of the Ministry of Industry and Information and is a major transportation equipment manufacturing enterprise in Jinan City.

At present, most tractor truck we exported are HOWO series, HOWO A7 series, which are very popular because of the reliable quality and competitive price, furthermore, the spare parts and after sales-service system are more improved than before. Therefore, HOWO series have been become main brand to recommend our oversea customers.

Applications:
Towing of vehicle with a traction device, designed for towing all kinds of semi-trailers

Competitive Advantage
1, Reliable, safe and comfortable appearance
2, High-strength structure & High safety design cabin
3, Most efficient dump truck in most reasonable price.
4, Giant amount of spare parts always ready for customers

10 wheels Sinotruk howo 371hp prime mover truck LHD or RHD commercial tractor truck head10 wheels Sinotruk howo 371hp prime mover truck LHD or RHD commercial tractor truck head
