Specifications
Brand Name :
XCMG
Model Number :
XE60
Certification :
ISO/CE/CCC/SGS
Place of Origin :
China
MOQ :
1pcs
Price :
$100000-200000
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Nude
Product Name :
excavator
Application :
Construction Industry
Maximum Digging Height :
6790mm
Model :
XE
Operating Weight :
6-16 tons
Bucket capacity :
0.3cbm
Standard :
ISO/CCC/SGS
Warranty :
12 months
Maximum Digging Depth :
2985mm
Machine Weight :
6t
Description

XCMG Mini Excavator XE215C Crawler excavator (more models for sale)

Product Description

Specification

- The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.

- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.

- Low emission meets the Europe II standard.

- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.

- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.

- Automatic preheating system improves the working capacity in the low temperature.

- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.

- Restart prevention system effectively avoids the misoperation, and improve s the use security of the machine.

Technical Parameter

Model Unit XE215C
Operating weight kg 21450
Standard bucket capacity m³ 0.8~1.0
Engine Engine Model / BB-6BG1TRP
Direct injection / √
Four strokes / √
Water cooling / √
Turbo charged / √
Air to air intercooler / ×
No. of cylinders / 6
Rated power/speed kw/rpm 106.5/1950
Max. torque/speed N.m 551/1600
Displacement L 6.494
The main performance Travel speed km/h 5.5/3.3
Swing speed r/min 13.3
Max. gradeability / ≥35
Ground pressure kPa 45.5
Max.Bucket digging force kN 138
Max.arm crowd force kN 103
Max.traction force kN 184
Hydraulic system Main pump / 2 Plunger pump
Rate flow of main pump L/min 2×206
Max pressure of prime relief valve MPa 31.5/34.4
Max pressure of travel system MPa 34.3
Max pressure of swing system MPa 28
Max pressure of pilot system MPa 3.9
Oil capacity Fuel tank capacity L 360
Hydraulic tank capacity L 220
Engine lubrication L 25
Overall dimensions A Overall length 9525MM
B Overall width 2990MM
C Overall height 3000MM
D Overall width of upperstructure 2710MM
E Track length 4270MM
F Overall width of undercarriage 2990MM
G Crawer width 600MM
H Track length on ground 3462MM
I Crawer gauge 2390MM
J Clearance under counter weight 1050MM
K Ground clearance 470MM
L Min.tail swing radius 2750MM
Working range A Max. digging height 9640MM
B Max. dumping height 6800MM
C Max. digging depth 6655MM
D 8inch horizonal digging depth 6470MM
E Max. vertical wall digging depth 5695MM
F Max. digging reach 9925MM
G Min. swing radius 3530MM
Angle of arm deflection Degree
