Specifications
Brand Name :
Remarkable
Model Number :
KPJ-50T
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, D/A, L/C, D/P, Western Union, MoneyGram
Supply Ability :
50 sets per month
Delivery Time :
45 days
Packaging Details :
The whole cart will be packed by the tarp, the parts will be packed by polywood case.
Color :
Customized
Application :
Industry metallurgy, Material handling/steel coil/industrial
Load capacity :
customized
Running speed :
0-20m/min
Size :
Customized Size
Power source :
cable drum powered
Usage :
material transferring
Safety features :
Warning alarm and End stop, end stop, Warning alarm
Control model :
wireless remote control+hand pendant
Safety facilities :
warning light, E-stop
Description

Heavy Industry Use 50 Tons Electric Steel Plamt Rail Transfer Trolleys

Storage battery of 24v, 36v, 48v supplies electricity to the dc motor. Then dc motor drives the battery transfer car to start, stop, go forward and backward and adjust its speed. This kind of transfer has no problem to work in explosive and flammable environment.

Applications:

♦ Metallurgy plant
♦ Shipbuilding industry
♦ Steel plant
♦ Warehouses
♦ Coal and oil industry
♦ Quarries
♦ Mine industry

Features:

◆ Frequently work
◆ Heavy type load
◆ Rail mounted
◆ Explosion proof and anti high temperature

Characters:


◆ Box girder structure cart frame to ensure table even load
◆ Design safety support
◆ Variable speed can be met
◆ Alarm light, limit switch

Heavy Industry Use 50 Tons Rail Transfer Trolley Electric Steel Plant

Technical parameters:

Technical parameters for Cable reel powered electric transfer carts KPJ series
Model KPJ-6t KPJ-10t KPJ-16t KPJ-25t KPJ-40t KPJ-63t KPJ-100t KPJ-160t KPJ-200t
Rated load (t) 6 10 16 25 40 63 100 160 200
Countertop size Length 3600 3600 4000 4500 5000 5600 6300 8000 8200
(mm) Width 2000 2000 2200 2200 2500 2500 2800 2800 3000
Height 550 550 600 650 700 850 900 1150 1250
Speed(m/min) 30 30 30 30 25 25 20 20 18
Wheel base A(mm) 2000 2200 2200 2500 2800 3200 3600 5000 5000
Track medial distance C(mm) 1435 1435 1435 1435 1635 1735 1850 2000 2000
Wheel diameter(mm) 300 300 400 400 500 600 700 700 700
Bottom clearance(mm) 50 50 50 60 60 60 60 70 70
Motor model / power YZ132M1-6 YZ132M2-6 YZ160M1-6 YZ160M2-6 YZ160L-6 YZ160M2-6 YZ160L-6
(Kw) 2.2 3.7 5.5 7.5 11 2×7.5 2×11
Power mode Cable drum AC380V AC380V AC380V
3×2.5+1×1.5 3×4+1×2.5 3×6+1×4
Recommended track model 24kg/m 24kg/m 38kg/m 43kg/m QU80 QU100
Number of wheels 4 8
Maximum wheel Pressure (t) 1.91 3.21 4.87 7.5 11.5 16.9 27.6 22.8 28.5
Reference weight (t) 3.4 3.72 4.2 6 8.5 11.4 15.2 25.5 31.5

1. Load capacity,table size and rail gauge can be customized.
2. Options: a.Remote radio control (imported or made in China);b.Automatic stop when detecting obstacle or person,limit switches(to limit travel);c.Battery type(Free of maintenance battery, lithium battery, explosion-proof battery, and anti-high temperature battery,)d.Motor(DC motor with brush and DC motor brushless )e.Electric parts(imported or made in China)
