Specifications
Brand Name :
Remarkable
Model Number :
KPJ-50T
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, D/A, L/C, D/P, Western Union, MoneyGram
Supply Ability :
50 sets per month
Delivery Time :
45 days
Packaging Details :
The whole cart will be packed by the tarp, the parts will be packed by polywood case.
Color :
Customized
Application :
Industry metallurgy, Material handling/steel coil/industrial
Power supply :
Cable Drum
Load capacity :
customized
Running speed :
0-20m/min
Size :
Customized Size
Usage :
material transferring
Safety features :
Warning alarm and End stop, end stop, Warning alarm
Control model :
wireless remote control+hand pendant
Description


Cable Drum Powered Rail Transfer Trolley 50 Tons Mold Plant Motorized Battery

Product Superiority----50 Tons Mold Plant Motorized Rail Transfer Trolley

1. This Series Of Flat Cars Has The Advantages Of Safety, Mobility And Flexibility, The Operation Is Not Limited By Distance, The Speed Is Adjustable, The Dc Motor Of Flat Cars Has The Advantages Of Stable Start, Large Start Torque, Small Impact On The Reducer, Low Voltage, Long Service Life And So On.

The Track Laying Requirements Are Not High, Suitable For Use Frequency Is Not High, Long-Distance Transport Occasions.

2. The Transfer Cart Adopts Dc Motor, Suitable For Frequent Use, With Higher Safety And Mobility Flexibility.

It Can Be Equipped With Hard Tooth Surface Reducer To Make The Maintenance Of Flat Car Easier.

3. This Series Of Electric Flat Car Mechanism Is Relatively Simple, Convenient For Maintenance, Easy To Disassemble And Assemble, Strong Bearing Capacity, Long Service Life, Low Requirement For Track Laying, Low Cost, Suitable For Harsh Environment, High-Temperature Environment, And Other Occasions.

4. Transfer Cart Is Suitable For All Kinds Of Environment, Can Work In Indoor, Outdoor, Flammable And Explosive Environment, Can Also Be Added To The Flat Car Hydraulic Device, Buffer Device. Simple Operation, In The Case Of Transport Distance Is Far, Can Be Added On The Flat Car With The Operating Platform, To Meet The Customer Long-Distance Transport, To Achieve A Humanized Design.

5. PLC Control System Can Be Added To The Flat Car, Automatic Rail Car, Greatly Increase The Work Efficiency.

Cable Drum Powered Rail Transfer Trolley 50 Tons Mold Plant Motorized BatteryCable Drum Powered Rail Transfer Trolley 50 Tons Mold Plant Motorized Battery

Technical parameters for Cable reel powered electric transfer carts KPJ series
Model KPJ-6t KPJ-10t KPJ-16t KPJ-25t KPJ-40t KPJ-63t KPJ-100t KPJ-160t KPJ-200t
Rated load (t) 6 10 16 25 40 63 100 160 200
Countertop size Length 3600 3600 4000 4500 5000 5600 6300 8000 8200
(mm) Width 2000 2000 2200 2200 2500 2500 2800 2800 3000
Height 550 550 600 650 700 850 900 1150 1250
Speed(m/min) 30 30 30 30 25 25 20 20 18
Wheel base A(mm) 2000 2200 2200 2500 2800 3200 3600 5000 5000
Track medial distance C(mm) 1435 1435 1435 1435 1635 1735 1850 2000 2000
Wheel diameter(mm) 300 300 400 400 500 600 700 700 700
Bottom clearance(mm) 50 50 50 60 60 60 60 70 70
Motor model / power YZ132M1-6 YZ132M2-6 YZ160M1-6 YZ160M2-6 YZ160L-6 YZ160M2-6 YZ160L-6
(Kw) 2.2 3.7 5.5 7.5 11 2×7.5 2×11
Power mode Cable drum AC380V AC380V AC380V
3×2.5+1×1.5 3×4+1×2.5 3×6+1×4
Recommended track model 24kg/m 24kg/m 38kg/m 43kg/m QU80 QU100
Number of wheels 4 8
Maximum wheel Pressure (t) 1.91 3.21 4.87 7.5 11.5 16.9 27.6 22.8 28.5
Reference weight (t) 3.4 3.72 4.2 6 8.5 11.4 15.2 25.5 31.5

Cable Drum Powered Rail Transfer Trolley 50 Tons Mold Plant Motorized Battery

Cable Drum Powered Rail Transfer Trolley 50 Tons Mold Plant Motorized BatteryCable Drum Powered Rail Transfer Trolley 50 Tons Mold Plant Motorized Battery

Cable Drum Powered Rail Transfer Trolley 50 Tons Mold Plant Motorized Battery

Cable Drum Powered Rail Transfer Trolley 50 Tons Mold Plant Motorized Battery
