Heavy Duty Factory Pallet 15 Tons Transfer Trolley With Remote Control
Our Heavy Duty Factory Pallet 15 Tons Transfer Trolley With Remote Control Are Designed To Accommodate The Needs Of A Wide Range Of Industries Including Steel, Nonferrous Metals, Aluminum, Automotive, Stamping, Heavy Manufacturing And Several Others. All Units Are Equipped With State Of The Art Safety Features Including Safety Lights, Horns, Bumpers, Dead Man Controls And Mushroom Type Emergency Stop Buttons. Our Trransfer Carts Equipped With Semi-Automatic And Fully Automatic Control Systems Come Equipped With A Wide Range Of Fully Automatic Safety Controls.
We Conceives And Manufactures A Wide Range Of Railway Guided Transfer Carts, Battery Powered Trolleys, Intelligent Self-Propelled Trolleys, Die Carts, Industrial Flat Trailers, Tilters And Lifting Platforms That Operate In Many Industrial Fields: Metallurgy, Manufacture, Oil And Gas, Die Shops, Shipyards, Chemical Plant, Automotive, Mining Industry, Aerospace, Power Generation, Coal Industry, Paper Mills, Metalworking, Warehouse And Many Others!
We can design and customize lifting table, roller frame, clamping device, high temperature explosion-proof and various special table according to the needs of customers.
Technical parameters for trackless electric transfer carts | ||||||||
Rated load(t) | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 150 |
Impacted rated loa(t) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 | 225 |
Structure of frame | steel plates welded, beam structure | |||||||
Max. wheel load(t) | 2.8 | 4.3 | 4.8 | 5.6 | 7.7 | 10 | 12 | 27 |
Ground requirement | cement floor | steel plate ground | ||||||
Table size(mm) | 3000× 2000 | 3600× 2000 | 4000× 2200 | 4500× 2200 | 5000× 2200 | 5500× 2300 | 6000× 2300 | 10000× 3000 |
Height of the whole cart(mm) | 450 | 530 | 600 | 600 | 650 | 700 | 700 | 1200 |
Ground clearanc(mm) | 50 | 75 | ||||||
Turning radius(mm) | 2501 | 3101 | 3401 | 3901 | 4301 | 4801 | 5201 | 10001 |
Turning type | turning while driving with no stop | |||||||
Control method for turning | control button | |||||||
Turning structure | mechanical | |||||||
Wheel material | ZG55+hydropur ture | |||||||
Running speed(m/min) | 0-15 | 0-12 | ||||||
Brake principle | electric magnetic brake | |||||||
Operation method | with wire or no wire | |||||||
Battery model | D-250x24 | D-33x24 | D-400x24 | D-440x24 | D-250x36 | D-330x36 | D-440x36 | D-600x36 |
Battery maintenance | free of maintenance | |||||||
Charger's installation | installed on cart | split-type |
Advantages of Mould transfer cart for automobile manufacturing industry - Heavy trackless transfer cart:
1. Low noise, no pollution.
2. High intelligence and automation.
3. Modular design, less parts, easy maintenance.
4. Small turning radius, suitable for narrow space.
5. Visual electric control box, touch screen control, convenient operation.
6. Customized laser width test auxiliary and roller bracket, etc., which make the transportation safer and more convenient.
7. The transfer cart can adapt to the fall road inside and outside the plant and has strong climbing ability.
8. Good safety, with the function of parking in case of obstacles, it can automatically slow down and stop when sensing obstacles.
9. Support all kinds of operation modes, such as straight, horizontal, turning, oblique, 360 in situ rotation, etc..
10. The transfer car can realize automatic operation, support path tracking, support remote control, reserve upper computer interface and provide communication protocol.
