Specifications
Brand Name :
Remarkable
Model Number :
RWP-40 Ton
Certification :
ISO,CE, ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
500 sets per year
Delivery Time :
30-45 work days
Packaging Details :
1. Main body of the machine is packed with high-quality waterproof plastic cloth. 2. Electrical parts are specially protected, and the spare parts are packed in standard export fumigation free wooden boxes.
Power supply :
Maintenance free battery
Load :
1-300 tons
Table size :
Customized
Operation method :
Wireless remote control & Hand operate pendant
Traveling speed(m/min) :
0-35 (Stepless speed regulation)
key words :
material transfer trolley, Industrial Transfer Carts,steerable transfer carts,electrical transfer cart
Battery charger function :
Automatic charging
Move Way :
Forward, backward, turning while driving with no stop
Usage :
Heavy Duty Material Transportation
Product name :
Battery Powered Transfer Trolley
Description

Heavy Duty Transporter Platform Material Handling Battery Powered Transfer Trolley

The RWP series can provide a load capacity of 0 ~ 500 ton for one vehicle, making them ideal for transporting large-size and large-tonnage workpieces. It can run on asphalt, self-leveling, concrete, steel and hard soil ground, and has a strong adaptability to ground conditions. Because it has the function of self-lifting of the whole vehicle, in addition to being used to directly carry the workpiece, it can also in directly carry the workpiece after self-supporting by drilling into the tooling frame and lifting the tooling frame. Multiple RWP trackless transfer trucks can be synchronized to support very large components, depending on user requirements. The trackless transporters can be remotely controlled and can also be used as a fully automated AGV transport system.

Heavy Duty Transporter Platform Material Handling Battery Powered Transfer Trolley

Heavy Duty Transporter Platform Material Handling Battery Powered Transfer Trolley

Technical parameters for electric transfer carts
1 rated load(t) 5 10 15 20 30 40 50 150
2 impacted rated load(t) 7.5 15 22.5 30 45 60 75 225
3 structure of frame steel plates welded, beam structure
4 max. wheel load(t) 2.8 4.3 4.8 5.6 7.7 10 12 27
5 ground requirement cement floor steel plate ground
6 table size(mm) 3000×2000 3600×2000 4000×2200 4500×2200 5000×2200 5500×2300

6000×

2300

10000×

3000

7 height of the whole cart(mm) 450 530 600 600 650 700 700 1200
8 ground clearance(mm) 50 75
9 wheels base(mm) 1500 1700 1800 2000
10 axles distance(mm) 2500 3100 3400 3900 4300 4800 5200 10000
11 turning radius(mm) 2501 3101 3401 3901 4301 4801 5201 10001
12 turning type turning while driving with no stop
13 control method for turning control button
14 turning structure mechanical
15 motor power(Kw) 3.5 5 6 7 10 12 15 15
16 wheel diameter(mm) Ф300 x 4 Ф350 x 4 Ф400 x 4 Ф400 x 6 Ф500 x 6 Ф600 x 8
21 battery model D-250 x 24 D-33 x 24 D-400 x 24 D-440 x 24 D-250 x 36 D-330 x 36 D-440 x 36 D-600 x 36
22 battery maintenance free of maintenance
23 charger's installation installed on cart split-type
24 charger function automatic charging
25 radar control 3-0.3m, automatic stop for obstacles
26 warning equipment sound and light
27 other functions turning light, night light and power display

Heavy Duty Transporter Platform Material Handling Battery Powered Transfer Trolley

After sales service commitment

Our company promises: the load-bearing safety factor of the electric flat car is not less than 120%.

According to the specific situation of users, we can design auxiliary devices or foundation drawings free of charge, and provide technical services or drawings. Free personnel to the user's installation and debugging or guidance installation and debugging qualified, to meet the user's satisfaction, sign and seal.

In case of quality problems of various parts of flat cars produced and sold by Henan Remarkable Intelligent Technology Co., Ltd., our company will implement "Three Guarantees" service according to the regulations, and the after-sales service department shall undertake this work.

After receiving the customer's information about the quality of parts and components (calls, letters), the after-sales service personnel shall give a reply within 2 hours, and send personnel to the scene within 24 hours, and rush to the scene in 12 hours for emergency problems. After sales hotline: 0373-3971116

While solving the quality problems of the sold products in time, the after-sales service personnel have the obligation to provide technical consultation, technical training and answer other product related problems free of charge.

During the warranty period (within one year after the installation, commissioning and acceptance are qualified and signed and sealed), if the products provided by our company are damaged due to quality problems or cannot work normally, we will repair or replace them free of charge. If outside the warranty period, we promise to charge only the cost.

Firmly establish the idea that the user is God, all for the sake of the user, efficient, serious, good from beginning to end, deal with quality issues, pay attention to credibility, and maintain the image of Henan Remarkable Intelligent Technology Co.,Ltd.

Heavy Duty Transporter Platform Material Handling Battery Powered Transfer Trolley

Heavy Duty Transporter Platform Material Handling Battery Powered Transfer TrolleyHeavy Duty Transporter Platform Material Handling Battery Powered Transfer TrolleyHeavy Duty Transporter Platform Material Handling Battery Powered Transfer Trolley

Heavy Duty Transporter Platform Material Handling Battery Powered Transfer Trolley

Heavy Duty Transporter Platform Material Handling Battery Powered Transfer Trolley

Heavy Duty Transporter Platform Material Handling Battery Powered Transfer Trolley
