Material 15 Tons Trackless Electric Flat Car 20m/min DC Motor Remote Control
Our Heavy Duty Platform Trolleys Are Synonymous With Advanced Customization And Adaptability For Cargo And Operators. Henan Remarkable 15 Tons Bay To Bay Battery Powered Die Transport Platform Design Flexibility Are Perfectly Suitable For A Complete Range Of Sectors And Applications With Particular Focus On Metalworking Industry, Tool And Dies Sector. We Designed Our Platform Truck Cart Series With Respect To Environment, Which Gives The Machine Greater Productivity As Well As Significant Saving In Maintenance And Consumables.
Advantages
(1) Maintenance-Free Battery
(2) Imported Speed Control Electronic Control, Two-Speed Control
(3) Imported Industrial Wireless Remote Control.
(4) Convenient, Flexible And Environmentally Friendly
15 Tons Trackless Electric Flat Car Is One Of Our Common And Mature Product, Which Is Customized As Per Customers' True Demand. Such As Power Supply, Operation System, Control System, Track Or No Track, Steerable, Wheelstype, Cart Frame Structure And So On, And Then Provide Proper Solution To You.
This Kind Of Trackless Transfer Car Is Powered By Battery, The Battery Is Installed In The Car, And Supply DC Electricity To The Control System, Which Makes The Car Start, Stop, Go Forward, Back Forward And So On.It Is Consist Of Battery, Motor, Reducer, Cart Frame, Electric Appliance, Etc.
Material 15T Battery Transfer Trolley Maintenance Free Battery Hand Operated.
Remarkable heavy duty platform carts are utilised to transfer large and bulky injection molds within production plants, in both medium and large sized companies. Especially in the automobile industry and mechanical equipment industry. These companies have numerous molds which on a daily basis must be transferred within the factory from a storage location to the molding presses, to maintenance rooms and so on. So, the most effective way is to use Battery power platform trolleys, Remarkable is a professional heavy duty platform carts manufacturer to improve their operations.
Technical parameters for electric transfer carts | |||||||||
1 | rated load(t) | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 150 |
2 | impacted rated load(t) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 | 225 |
3 | structure of frame | steel plates welded, beam structure | |||||||
4 | max. wheel load(t) | 2.8 | 4.3 | 4.8 | 5.6 | 7.7 | 10 | 12 | 27 |
5 | ground requirement | cement floor | steel plate ground | ||||||
6 | table size(mm) | 3000×2000 | 3600×2000 | 4000×2200 | 4500×2200 | 5000×2200 | 5500×2300 | 6000× 2300 | 10000× 3000 |
7 | height of the whole cart(mm) | 450 | 530 | 600 | 600 | 650 | 700 | 700 | 1200 |
8 | ground clearance(mm) | 50 | 75 | ||||||
9 | wheels base(mm) | 1500 | 1700 | 1800 | 2000 | ||||
10 | axles distance(mm) | 2500 | 3100 | 3400 | 3900 | 4300 | 4800 | 5200 | 10000 |
11 | turning radius(mm) | 2501 | 3101 | 3401 | 3901 | 4301 | 4801 | 5201 | 10001 |
12 | turning type | turning while driving with no stop | |||||||
13 | control method for turning | control button | |||||||
14 | turning structure | mechanical | |||||||
15 | motor power(Kw) | 3.5 | 5 | 6 | 7 | 10 | 12 | 15 | 15 |
16 | wheel diameter(mm) | Ф300 x 4 | Ф350 x 4 | Ф400 x 4 | Ф400 x 6 | Ф500 x 6 | Ф600 x 8 | ||
21 | battery model | D-250 x 24 | D-33 x 24 | D-400 x 24 | D-440 x 24 | D-250 x 36 | D-330 x 36 | D-440 x 36 | D-600 x 36 |
22 | battery maintenance | free of maintenance | |||||||
23 | charger's installation | installed on cart | split-type | ||||||
24 | charger function | automatic charging | |||||||
25 | radar control | 3-0.3m, automatic stop for obstacles | |||||||
26 | warning equipment | sound and light | |||||||
27 | other functions | turning light, night light and power display |
