Semi Automatic Wire Winder High Voltage Transformer Coil Winding Machine
Semi Automatic Wire Winder High Voltage Transformer Coil Winding Machine
Specifications
Brand Name :
STT
Model Number :
GDY-2T
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T, L/C
Supply Ability :
100 sets per year
Delivery Time :
20 days
Packaging Details :
seaworthy packing
Name :
transformer coil winding machine
Usage :
winding wire coils
Center height :
1000mm
Shaft size :
40x40x1500mm
Tail stock :
live centre
Color :
optional
Counter :
digital
Winding Speed :
0 ~ 80rpm
Description

Semi Automatic Wire Winder High Voltage Transformer Coil Winding Machine

Description of transformer coil winding machine GDY-2T

Transformer coil winding machine GDY-2T is a professional winding equipment, which is mainly used to wind transformer coils. The transformer coil winding machine can wind different sizes of copper and aluminium wires. These wound coils can be used in transformers or other similar products. The transformer coil winding machine is provided with main winding motor, tail stock, counter, foot pedal and so on. The foot pedal of the coil winding machine can stop and run the machine and switch the rotating direction. The transformer features slow starting, smooth running, big torque and easy operation etc.

Main features of transformer coil winding machine GDY-2T

  • Slow starting
  • Smooth running
  • Easy operation
  • Big torque

Main parameters of transformer coil winding machine GDY-2T

Typical standard specifications of coil winding machine GDY-2T are shown below and the transformer coil winding machine can also be manufactured as requested.

Shaft Height From Floor: 1000mm
Distance Between Ends: 1500mm
Winding Speed: 0 ~ 80rpm
Speed Gear: 2 pcs
Max. Winding Length: 1200mm
Counting Range: 0 ~ 9999.9
Max. Loading Capacity: 2000KG
Motor Power: 5.5KW
Colour: optional
Machine Dimension(L*W*H): 2800*700*1400mm

Semi Automatic Wire Winder High Voltage Transformer Coil Winding Machine

Fig 1: Transformer coil winding machine GDY-2T's full view

Semi Automatic Wire Winder High Voltage Transformer Coil Winding Machine

Fig 2: Transformer coil winding machine GDY-2T's control board

Semi Automatic Wire Winder High Voltage Transformer Coil Winding Machine
