ADP5300ACPZ-3-R7 Power Management ICs Switching Voltage Regulator IC
ADP5300ACPZ-3-R7 Power Management ICs Switching Voltage Regulator IC
ADP5300ACPZ-3-R7 Power Management ICs Switching Voltage Regulator IC
ADP5300ACPZ-3-R7 Power Management ICs Switching Voltage Regulator IC
Specifications
Brand Name :
Original
Model Number :
ADP5300ACPZ-3-R7
Certification :
ISO9001:2015standard
Place of Origin :
Original
MOQ :
10
Price :
contact us to win best offer
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,paypal
Supply Ability :
10000pcs/months
Delivery Time :
1-3workdays
Packaging Details :
Standard
Type :
DC-DC Voltage Converter
Product Category :
Switching Voltage Regulators
Topology :
Buck
Output Voltage :
800 mV to 5 V
Development Kit :
EVAL-ADP5300
Moisture Sensitive :
Yes
Description

ADP5300ACPZ-3-R7 Power Management ICs TLE8457BSJXUMA1 SI4850EY-T1-GE3 Regulators & Voltage Controllers

Features:

The ADP5300 is a high efficiency, ultralow quiescent current step-down regulator that draws only 180 nA quiescent current to regulate the output. The ADP5300 runs from an input supply voltage range of 2.15 V to 6.50 V, allowing the use of multiple alkaline or NiMH, Li-Ion cells, or other power sources. The output voltage is selectable from 0.8 V to 5.0 V by an external VID resistor and factory fuse. The total solution requires only four tiny external components. The ADP5300 can operate between hysteresis mode and pulsewidth modulation (PWM) mode via the SYNC/MODE pin. The regulator in hysteresis mode achieves excellent efficiency at a power of less than 1 mW and provides up to 50 mA of output current. The regulator in PWM mode produces a lower output ripple and supplies up to 500 mA of output current. The flexible configuration capability during operation of the device enables very efficient power management to meet both the longest battery life and low system noise requirements.

ADP5300ACPZ-3-R7 Power Management ICs Switching Voltage Regulator ICADP5300ACPZ-3-R7 Power Management ICs Switching Voltage Regulator IC

Product Attribute Attribute Value
Switching Voltage Regulators
SMD/SMT
LFCSP-10
Buck
800 mV to 5 V
500 mA
1 Output
2.15 V
6.5 V
425 uA
2 MHz
- 40 C
+ 125 C
ADP5300
Reel
Cut Tape
MouseReel
Development Kit: EVAL-ADP5300
Input Voltage: 2.15 V to 6.5 V
Moisture Sensitive: Yes
Product Type: Switching Voltage Regulators
Shutdown: Shutdown
1500
Subcategory: PMIC - Power Management ICs
Supply Voltage - Min: 2.15 V
Type: DC-DC Voltage Converter
Unit Weight: 0.000716 oz
