UCC27524ADR IGBT MOSFET Door Gate Drivers AT91SAM9G10-CU CY8C24123A-24SXI PMIC ICs
UCC27524ADR IGBT MOSFET Door Gate Drivers AT91SAM9G10-CU CY8C24123A-24SXI PMIC ICs
UCC27524ADR IGBT MOSFET Door Gate Drivers AT91SAM9G10-CU CY8C24123A-24SXI PMIC ICs
UCC27524ADR IGBT MOSFET Door Gate Drivers AT91SAM9G10-CU CY8C24123A-24SXI PMIC ICs
Specifications
Brand Name :
Original
Model Number :
UCC27524ADR
Certification :
ISO9001:2015standard
Place of Origin :
Original
MOQ :
10pcs
Price :
Contact us to win best offer
Payment Terms :
L/C, T/T, Western Union, PayPal
Supply Ability :
10000pcs/months
Delivery Time :
1-3week days
Packaging Details :
standard
Type :
Low-Side
Installation style :
SMD/SMT
Package/case :
SOIC-8
Configuration :
Non-Inverting
Features :
Enable Pin
Unit weight :
76 mg
Description

UCC27524ADR IGBT MOSFET Door Gate Drivers AT91SAM9G10-CU CY8C24123A-24SXI PMIC Power Management ICs

1 Features

• Industry-Standard Pin Out

• Two Independent Gate-Drive Channels

• 5-A Peak Source and Sink-Drive Current

• Independent-Enable Function for Each Output

• TTL and CMOS Compatible Logic Threshold Independent of Supply Voltage

• Hysteretic-Logic Thresholds for High Noise Immunity

• Ability to Handle Negative Voltages (–5 V) at Inputs

• Inputs and Enable Pin-Voltage Levels Not Restricted by VDD Pin Bias Supply Voltage

• 4.5 to 18-V Single-Supply Range

• Outputs Held Low During VDD-UVLO (Ensures Glitch-Free Operation at Power Up and Power Down)

• Fast Propagation Delays (13-ns Typical)

• Fast Rise and Fall Times (7-ns and 6-ns Typical)

• 1-ns Typical Delay Matching Between 2-Channels

• Two Outputs are Paralleled for Higher Drive Current

• Outputs Held in Low When Inputs Floating

• SOIC-8, HVSSOP-8 PowerPAD™ Package Options

• Operating Temperature Range of –40 to 140°C

2 Applications

• Switch-Mode Power Supplies Dual Non-Inverting Inputs

• DC-to-DC Converters

• Motor Control, Solar Power

• Gate Drive for Emerging Wide Band-Gap Power Devices Such as GaN

Product Category: Gate Drivers
IGBT, MOSFET Gate Drivers
Low-Side
SMD/SMT
SOIC-8
2 Driver
2 Output
5 A
4.5 V
18 V
Non-Inverting
7 ns
7 ns
- 40 C
+ 140 C
UCC27524A
Reel
Cut Tape
Features: Enable Pin
Operating Supply Current: 110 uA
Operating Supply Voltage: 4.5 V to 18 V
Product Type: Gate Drivers
Factory Pack Quantity: 2500
Subcategory: PMIC - Power Management ICs
Technology: Si
Unit Weight: 0.002677 oz

UCC27524ADR IGBT MOSFET Door Gate Drivers AT91SAM9G10-CU CY8C24123A-24SXI PMIC ICs

UCC27524ADR IGBT MOSFET Door Gate Drivers AT91SAM9G10-CU CY8C24123A-24SXI PMIC ICs

Related stock models

DS2430AP+ 680
LTC7004EMSE#TRPBF 17322
LT8607EDC#TRMPBF 1950
LTC6652AHMS8-1.25#PBF 300
BSZ100N03MSGATMA1 10000

Company Advantages

1. We can offer products according to customer's BOM list. One stop purchase.

2. All kinds of chips, various types and complete brands.

3.More than 15years for sales original IC parts.

4. Comprehensive customer service: from customer consultation to after sales service.

5. Walton can offer sample for free , but client have to pay shipping cost. Contact us if needed.

Professional consultation: Hanna

Contact Number/Whatsapp: +86-199 2879 8470

Skype :walton-sales5@walton-ic.com

Email: walton-sales5@walton-ic.com
