SI8662BB-B-IS1 Integrated Circuit Chip SOIC-Narrow-16 6 Channel Digital Isolator IC
SI8662BB-B-IS1 Integrated Circuit Chip SOIC-Narrow-16 6 Channel Digital Isolator IC
SI8662BB-B-IS1 Integrated Circuit Chip SOIC-Narrow-16 6 Channel Digital Isolator IC
SI8662BB-B-IS1 Integrated Circuit Chip SOIC-Narrow-16 6 Channel Digital Isolator IC
SI8662BB-B-IS1 Integrated Circuit Chip SOIC-Narrow-16 6 Channel Digital Isolator IC
SI8662BB-B-IS1 Integrated Circuit Chip SOIC-Narrow-16 6 Channel Digital Isolator IC
Specifications
Brand Name :
Original
Model Number :
SI8662BB-B-IS1
Certification :
ISO9001:2015standard
Place of Origin :
Original
MOQ :
10
Price :
contact us to win best offer
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,paypal
Supply Ability :
10000pcs/months
Delivery Time :
1-3workdays
Packaging Details :
Standard
Package :
SOT23-6L
D/c :
Newest
Packaging :
Standard Packing
Shipping by :
DHL\UPS\Fedex\EMS\HK Post,DHL\UPS\Fedex\EMS\HK Post\TNT
Package / case :
DIP8
Description :
Integrated Circuits (ICs)
Description

SI8662BB-B-IS1 Semiconductors Interface ICs Isolators SI8662BB-B-IS1R BAV70 Digital

Feature:

Skyworks' family of ultra-low-power digital isolators are CMOS devices offering substan tial data rate, propagation delay, power, size, reliability, and external BOM advantages over legacy isolation technologies.

The operating parameters of these products remain stable across wide temperature ranges and throughout device service life for ease of design and highly uniform performance. All device versions have Schmitt trigger inputs for high noise immunity and only require VDD bypass capacitors.

Data rates up to 150 Mbps are supported, and all devices achieve propagation delays of less than 10 ns.

Ordering options include a choice of isolation ratings (1.0, 2.5, 3.75 and 5 kV) and a selectable fail-safe operating mode to control the default output state during power loss.

All products >1 kVRMS are safety certified by UL, CSA, VDE, and CQC, and products in wide-body packages support reinforced insulation withstanding up to 5 kVRMS. Automotive Grade is available for certain part numbers.

These products are built using automotive-specific flows at all steps in the manufacturing process to ensure the robustness and low defectivity required for automotive applications.

SI8662BB-B-IS1 Integrated Circuit Chip SOIC-Narrow-16 6 Channel Digital Isolator IC

SI8662BB-B-IS1 Integrated Circuit Chip SOIC-Narrow-16 6 Channel Digital Isolator IC

SI8662BB-B-IS1 Integrated Circuit Chip SOIC-Narrow-16 6 Channel Digital Isolator IC

Product Attribute Attribute Value
Digital Isolators
Si886x
SMD/SMT
SOIC-Narrow-16
6 Channel
Unidirectional
150 Mb/s
2500 Vrms
Capacitive Coupling
5.5 V
2.5 V
19.4 mA
10 ns
- 40 C
+ 125 C
AEC-Q100
Tube
Moisture Sensitive: Yes
Operating Supply Voltage: 2.5 V to 5.5 V
Pd - Power Dissipation: 415 mW
Product Type: Digital Isolators
48
Subcategory: Interface ICs
Type: General Purpose
Unit Weight: 0.019401 oz
