Specifications
Brand Name :
GALAXY
Model Number :
GS90
Certification :
ISO,CE
Place of Origin :
Jiangsu province,China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
15-25 days
Supply Ability :
100 sets per month
Packaging Details :
Container
Product Name :
9Ton Power Line Stringing Equipment
Max pull :
90KN
Diesel :
118kw(158hp)
Electrical system :
24V
Bull-wheel diameter :
540mm
Max rope diameter :
21mm
Engine :
Cummins
Application :
Transmission Overhead Power Lines
Description

Pulling 330KV ADSS Cable 8 Grooves 90KN Power Line Stringing Equipment

9Ton Power Line Stringing Equipment

Our GS90 90KN Hydraulic Puller Machine the spring applied hydraulically released brake can act automatically.

Thus, the secure operation of our 90KN hydraulic puller can be well ensured, when the motor suddenly turns off

or other reasons cause the hydraulic failure.

Thanks to the hydraulic type rope clamping device, it is easy to replace the steel wire rope reel.

Additionally, our machine is equipped with the steel wire rope automatically winding device,

which can automatically arrange the rope and also make loading and unloading convenient.

9Ton Power Line Stringing Equipment Quick details:
90KN Cable Stringing Equipment For transmission line construction
Hydraulic Puller Tensioner Dual Purpose Machine
Max pull: 90kN
Diesel: Cummins 118kw(158hp)
Main pump and motor: German Rexroth
Speed Reducer: German Rexroth
Bull-wheel diameter: 540mm
Max rope diameter:21mm
Max conductor diameter: 40mm

GALAXY Brand
9Ton Power Line Stringing Equipment Performance
Max pull: 90kN
Speed at max pull: 2.4km/h
Max speed: 5km/h
Pull at max speed: 44kN
Max Tension: 90kN
Max Speed: 5km/h
9Ton Power Line Stringing Equipment Engine
Diesel 118kw(158hp)
Cooling system water
Electrical system 24V
9Ton Power Line Stringing Equipment Characteristics
Bull-wheel diameter: 540mm
Max rope diameter : 21mm
Max conductor diameter: 40mm
Total weight: 4600kg
Overall dimension (length*width*height): 4700×2300×2700mm

Main configuration
Engine: Cummins
Main pump: German Rexroth
Main motor speed reducer: German Rexroth

Operating handle: German Rexroth
Hydraulic meter: German
Configuration
Negative self-acting hydraulic brakes
Hydraulic dynamometers with set-point and automatic control of maximum pull
Hydraulic oil cooling system
Digital meter counters
Control instruments for hydraulic system and diesel engine
Rigid axles for towing at max speed of 30km/h with mechanical parking brake
Hydraulic power pack to control up to 2 reel stands with hydraulic head or 2 reel winders with independent controls
Hydraulic front stabilizer
Grounding connection point
Hydraulic Transmission
Closed hydraulic circuit for step less speed variation in both rotating directions. This machine is provided with 2 pull pro-setting system that maintains the pre-set pulling value (also when the speed is reduced to "0") by automatically adjusting the operation speed according to the friction and unexpected loads which may occur.
Additional Devices
Lighting system for the trailer
Hydraulic brake system for the trailer(extra charge)
2 hydraulic conductor clamps for drum change
operations (extra charge)
Electronic pull and speed recorder
