One-Piece Clamp Style Collar SCS-2 SCS-3 SCS-4 SCS-5 SCS-6 SCS-7 SCS-8 SCS-9 SCS-10 SCS-11 SCS-12 SCS-13 SCS-14 SCS-15
One-Piece Clamp Style Collar SCS-2 SCS-3 SCS-4 SCS-5 SCS-6 SCS-7 SCS-8 SCS-9 SCS-10 SCS-11 SCS-12 SCS-13 SCS-14 SCS-15
Specifications
Place of Origin :
China
Brand Name :
MW
Certification :
ISO
Model Number :
SCS-2,SCS-3, SCS-4, SCS-5, SCS-6, SCS-7, SCS-8, SCS-9, SCS-10, SCS-11, SCS-12, SCS-13, SCS-14, SCS-15, SCS-16, SCS-17, SCS-18, SCS-19, SCS-20, SCS-21, SCS-22, SSC-23, SCS-24, SCS-25, SCS-26, SCS-27, SCS-28, SCS-29, SCS-30, SCS-31, SCS-32, SCS-33, SCS-34, S
MOQ :
10 Pieces
Price :
Negotiation
Packaging Details :
As per customer's request
Delivery Time :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
100000 Pieces /Month
Description

One-Piece Clamp Style Collar SCS-2 SCS-3 SCS-4 SCS-5 SCS-6 SCS-7 SCS-8 SCS-9 SCS-10 SCS-11 SCS-12 SCS-13 SCS-14 SCS-15

Quick Detail:

One-Piece Clamp Style Collar, Shaft Collars, Threaded Bore Split Collars, Inch Series Shaft Collars, Single And Double Split Collars

Standard and non-standard available

With high quality and competitive price

Prompt delivery

Packing as per customer’s demand.

Description:

One-Piece Clamp Style Collar, Shaft Collars, Threaded Bore Split Collars, Inch Series Shaft Collars, Single And Double Split Collars

1, Does not mar the shaft

2, Single point faced

3, Width tolerance: +.003¡± - .010¡±

We can also supply One-Piece Clamp Style Collar, Shaft Collars, Threaded Bore Split Collars, Inch Series Shaft Collars, Single And Double Split Collars as below:

SCS-2,SCS-3, SCS-4, SCS-5, SCS-6, SCS-7, SCS-8, SCS-9, SCS-10, SCS-11, SCS-12, SCS-13, SCS-14, SCS-15, SCS-16, SCS-17, SCS-18, SCS-19, SCS-20, SCS-21, SCS-22, SSC-23, SCS-24, SCS-25, SCS-26, SCS-27, SCS-28, SCS-29, SCS-30, SCS-31, SCS-32, SCS-33, SCS-34, SCS-35, SCS-36, SCS-37, SCS-38, SCS-39, SCS-40, SCS-41, SCS-42, SCS-43, SCS-44, SCS-45, SCS-46, SCS-47, SCS-48

China manufacturer of shaft collars, Specialist in: solid shaft collars, single and double split collars, threaded bore split collars, Inch Series shaft collars, Metric Series shaft collars, Set Screw Style Collar.

Applications:

One-Piece Clamp Style Collar, Shaft Collars, Threaded Bore Split Collars, Inch Series Shaft Collars, Single And Double Split Collars is used in reducing labor and downtime when adjustment, removal, or replacement

Specification:

One-Piece Clamp Style Collar SCS-2 SCS-3 SCS-4 SCS-5 SCS-6 SCS-7 SCS-8 SCS-9 SCS-10 SCS-11 SCS-12 SCS-13 SCS-14 SCS-15

One-Piece Clamp Style Collar SCS-2 SCS-3 SCS-4 SCS-5 SCS-6 SCS-7 SCS-8 SCS-9 SCS-10 SCS-11 SCS-12 SCS-13 SCS-14 SCS-15

PART NUMBER STEEL

PART NUMBER ALUMINUM

PART NUMBER STAINLESS STEEL

OUTER DIAM. OD (in)

WIDTH W (in)

FORGED SET SCREW

SCS-2-FL-2-F

SCS-2-A

SCS-2-SS

5/8

0.281

4-40X5/16

SCS-3-F

SCS-3-A

SCS-3-SS

5/8

0.281

4-40X5/16

SCS-4-F

SCS-4-A

SCS-4-SS

5/8

0.281

4-40X5/16

SCS-5-F

SCS-5-A

SCS-5-SS

11/16

0.281

4-40X5/16

SCS-6-F

SCS-6-A

SCS-6-SS

7/8

0.343

6-32X3/8

SCS-7-F

SCS-7-A

SCS-7-SS

15/16

0.343

6-32X3/8

SCS-8-F

SCS-8-A

SCS-8-SS

1.125

0.406

8-32X1/2

SCS-9-F

SCS-9-A

SCS-9-SS

1.25

0.437

10-32X1/2

SCS-10-F

SCS-10-A

SCS-10-SS

1.3125

0.437

10-32X1/2

SCS-11-F

SCS-11-A

SCS-11-SS

1.375

0.437

10-32X1/2

SCS-12-F

SCS-12-A

SCS-12-SS

1.5

0.5

1/4-28X5/8

SCS-13-F

SCS-13-A

SCS-13-SS

1.625

0.5

1/4-28X5/8

SCS-14-F

SCS-14-A

SCS-14-SS

1.625

0.5

1/4-28X5/8

SCS-15-F

SCS-15-A

SCS-15-SS

1.75

0.5

1/4-28X11/16

SCS-16-F

SCS-16-A

SCS-16-SS

1.75

0.5

1/4-28X11/16

SCS-17-F

SCS-17-A

SCS-17-SS

1.875

0.5

1/4-28X11/16

SCS-18-F

SCS-18-A

SCS-18-SS

1.875

0.5

1/4-28X11/16

SCS-19-F

SCS-19-A

SCS-19-SS

2.0625

0.5

1/4-28X11/16

SCS-20-F

SCS-20-A

SCS-20-SS

2.0625

0.5

1/4-28X11/16

SCS-21-F

SCS-21-A

SCS-21-SS

2.125

0.563

1/4-28X3/4

SCS-22-F

SCS-22-A

SCS-22-SS

2.25

0.563

1/4-28X3/4

SCS-23-F

SCS-23-A

SCS-23-SS

2.25

0.563

1/4-28X3/4

SCS-24-F

SCS-24-A

SCS-24-SS

2.375

0.563

1/4-28X3/4

SCS-25-F

SCS-25-A

SCS-25-SS

2.375

0.563

1/4-28X3/4

SCS-26-F

SCS-26-A

SCS-26-SS

2.625

0.688

5/16-24X7/8

SCS-27-F

SCS-27-A

SCS-27-SS

2.75

0.688

5/16-24X7/8

SCS-28-F

SCS-28-A

SCS-28-SS

2.75

0.688

5/16-24X7/8

SCS-29-F

SCS-29-A

SCS-29-SS

2.875

0.688

5/16-24X7/8

SCS-30-F

SCS-30-A

SCS-30-SS

2.875

0.688

5/16-24X7/8

SCS-31-F

SCS-31-A

SCS-31-SS

3

0.688

5/16-24X7/8

SCS-32-F

SCS-32-A

SCS-32-SS

3

0.688

5/16-24X7/8

SCS-33-F

SCS-33-A

SCS-33-SS

3.125

0.75

5/16-24X7/8

SCS-34-F

SCS-34-A

SCS-34-SS

3.25

0.75

5/16-24X7/8

SCS-35-F

SCS-35-A

SCS-35-SS

3.25

0.75

5/16-24X7/8

SCS-36-F

SCS-36-A

SCS-36-SS

3.25

0.75

5/16-24X7/8

SCS-37-F

SCS-37-A

SCS-37-SS

3.375

0.75

5/16-24X1

SCS-38-F

SCS-38-A

SCS-38-SS

3.5

0.75

5/16-24X1

SCS-39-F

SCS-39-A

SCS-39-SS

3.5

0.75

5/16-24X1

SCS-40-F

SCS-40-A

SCS-40-SS

3.75

0.875

3/8-24X1

SCS-41-F

SCS-41-A

SCS-41-SS

3.875

0.875

3/8-24X1

SCS-42-F

SCS-42-A

SCS-42-SS

3.875

0.875

3/8-24X1

SCS-43-F

SCS-43-A

SCS-43-SS

4

0.875

3/8-24X1

SCS-44-F

SCS-44-A

SCS-44-SS

4

0.875

3/8-24X1

SCS-45-F

SCS-45-A

SCS-45-SS

4.25

0.875

3/8-24X1 1/8

SCS-46-F

SCS-46-A

SCS-46-SS

4.25

0.875

3/8-24X1 1/8

SCS-47-F

SCS-47-A

SCS-47-SS

4.25

0.875

3/8-24X1 1/8

SCS-48-F

SCS-48-A

SCS-48-SS

4.25

0.875

3/8-24X1 1/8

Note: Sizes SCS-25 through SCS-48 do not have backslot.

Competitive Advantage:

More than 20 years advanced technology and experience of us will give strong support for the One-Piece Clamp Style Collar, Shaft Collars, Threaded Bore Split Collars, Inch Series Shaft Collars, Single And Double Split Collars you need. We will understand your need of product quickly, and give quick respond and good service. A lot of cases of our products will show you that it worth your trust.

Under the full quality control system, our products go through the precise product line and strict testing process. We have excellent working flow and standard to ensure stability, products reliable enough for using.

Take our scale economy, raw material superiority, and sincerity for clients to account, our price have a great competitiveness. They are good value and cost effective than your imagine.

We sincerely hope establishing long and friendly business relations with clients from all over the world. Our goal is not just providing product, but also providing a complete solution including product design, tooling, fabrication and service for our customers to achieve their upmost satisfaction.
