Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mA
Specifications
Brand Name :
Yunyi
Model Number :
YD322-A
Certification :
ISO CE
Place of Origin :
China
MOQ :
1
Price :
USD$36.82-USD$52.98/Unit
Payment Terms :
T/T, Western Union ,paypal
Supply Ability :
10000 unit/month
Delivery Time :
5-10 working days
Packaging Details :
Standard export package
Power supply :
24VDC, 12VDC
Measure range :
0-200m
Medium temp :
-20 to 80°C
Accuracy :
0.5% or 0.25%
Output :
4-20ma, 0-5v, 0-10v
Process connection :
M20*1.5, 1/2npt, 1/4npt
Warranty :
365 days
Description

Descroption of Water Level Sensor Transmitter Submersible Type

Submersible type water level sensor transmitter is comsed of full sealed isolation membrane filled level sensor

and special instrument circuit. With the advantages of high measuring precision, good stability, long service

life, convenient installation, etc.With unique technology of sealing structure form, and good anti-leakage performance, immersed in a liquid reliable operation for a long time.

Detailed Images of Water Level Sensor Transmitter Submersible Type

Submersible Type Water Level Sensor Transmitter LCD Digital Display 4mASubmersible Type Water Level Sensor Transmitter LCD Digital Display 4mA

Specification of Water Level Sensor Transmitter Submersible Type

1 Measurement object: liquid level of water, oil, paste
2 Measuring range: 0 - 200m
3 Output signal: 4 ~ 20mA or 0 ~ 10mA
4 Power supply voltage: 24VDC
5 Temperature: -20 to 80℃
6 Index Table: user select
7 Material: die-casting aluminum alloy shell, epoxy coating surface
8 Diaphragm: 316 stainless steel
9 Probe: 1Cr18Ni9Ti

Features of Water Level Sensor Transmitter Submersible Type

1.Prevent from the surge voltage, over-voltage, over-current and the protection of reversed polarity;
2.Do the test to make sure the ability of overload resistance and shock resistance,precisely ensure the overloadcapacity;
3.Implement the electromagnetic interference resistance to avoid the problem taken place under the condition of complicated electromagnetism environment;
4.All sensitive chips are from the imported OEM parts,in order to keep the long-term stability.

Application of Water Level Sensor Transmitter Submersible Type

Submersible type water level sensor transmitter is mainly used for petrochemical, metallurgy, electric power, pharmaceuticals, water supply and drainage, environmental protection and other systems and industries of the liquid level measurement.

Slection Guide of Water Level Sensor Transmitter Submersible Type

CODE Level transmitter mode
2088T A Cable type
CODE Measurement Range
1 (0-1)mH2O
2 (0-5)mH2O
3 (0-10)mH2O
4 (0-20)mH2O
5 (0-30)mH2O
T Special specification
CODE Accuracy grade
1 0.2
2 0.5
CODE Explosion proof type
N Standard type
i EX iaⅡCT6
d EX dⅡBT4
CODE display
M0 None
M1 LCD digital display
CODE Output
E 4~20mA
V 0-5V
S 0-10V
T Special specification
CODE Probe material
A1 SUS304
A2 SUS316L
CODE Cable sheath material
B1 Polyethylene rubber
B2 PTFE
B3 Teflon
CODE Power supply
V1 24V DC
V2 Special specification
FAQ
Q: How long will you reply me?
A: We will contact you as soon as possible but within 12 hours.
Q: Can I get some samples?
A: Yes, Sample order is available for quality check and market test. But you have to pay the express cost.
Q: How soon can you arrange your production?
A: Once getting your product confirmation and receiving the prepayment, the production will be started immediately.
Q: What's delivery time?
A: It usually takes about 3-5 working days for small order and 10-15 days for big order.
Q: How do you control your quality ?
A: Three inspection steps(of original, production, and finished goods) + good warranty service(1 year free to change a new one without any human damage factors).
Q: What certificates do you have ?
A: ISO9000, CE, Explosion-proof certification, RoHs ready. And before the delievry of goods, quality and safety inspection certification issued by third parts also can be offered.
Q: Could I visit your factory?
A: Very welcome! Fly to Xian Yang air port. It was a big pleasure for us.
Q: What's your warranty terms?
A: We offer 12 months warranty time.
Q: Can you provide OEM & Customized service?
A: Yes, OEM and ODM are both available, we have the professional R&D dept which can provide professional solutions for you.
