Specifications
Brand Name :
Yunyi
Model Number :
YD33
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
89~120USD/PCS
Payment Terms :
T/T, Western Union
Supply Ability :
100pcs per week
Delivery Time :
10 work days
Packaging Details :
Carton Packaging
Pressure range :
0-10Mpa
Output :
4-20mA 2 wire, 0-10V,0-5V,1-5V 3 wire ,RS485
Power :
10-30VDC
Thread :
G1/2npt
Accuracy :
0.25%
Housing protection :
IP65
Description

Flush Diaphragm Pressure Transmitter High Quality Tri Clamp Hygienic Sanitary Pressure Transmitter

Description

Flush diaphragm pressure transmitter, designed for food and pharmaceutical industry, is suitable

for CIP/SIP cleaning and sterilization.Smart compact design, the welded process diaphragm medium parts is made ofhigh quality stainless steel 316L, filling fluid with hygiene standard in line with certification,variety of international standard process connections are available.

Detailed Images

Specification

Range: 0-35/50/100/200/400/500/600Kpa

0-1/1.6/2.5/4/6/10Mpa

Accuracy: 0.25% FS; 0.5% FS; 1% FS

Output signal: 4-20mA (two-wire), 0-5V; 0-10V (three-wire)

Supply voltage: 24 (12 ~ 36) VDC,

Pressure connection: G1 / 2, M12 * 1.5,or clamp type

Electrical connection: DIN, directly lead , aviation plug-ins

Hysteresis & non-linear & Repeatability: ≤ ± 0.5% FS

Comprehensive error (including temperature drift): ≤ ± 1% FS (-20 ~ 80 ℃)

Long-term stability: ≤ ± 0.25% FS 1 Year

Medium temperature range: -40 ~ 85℃(thread type)-40 ~ 150 ℃(clamp type)

Storage temperature range: -40 ~ 85 ℃

Features

Improved optimized circuit and mounting structure, improved vibration resistance and stability

No cavity measuring diaphragm chamber;

Many industry-standard signal output options;

Wiring for the connector or directly lead;

May request for additional full-scale zero adjustment function;

Various pressure port option;

Applications

Aspects of mechanical engineering applications, such as polyurethane equipment

Medical applications such as pharmaceutical and other

Food Machinery and beverage processing industry

General industrial control field, such as paper, paint, etc.
