100MPa Digital Smart Air Oil Pressure Transmitter RS232
100MPa Digital Smart Air Oil Pressure Transmitter RS232
100MPa Digital Smart Air Oil Pressure Transmitter RS232
100MPa Digital Smart Air Oil Pressure Transmitter RS232
Specifications
Brand Name :
YUNYI
Model Number :
2088
Certification :
ce
Place of Origin :
china
MOQ :
1
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
1000pcs/month
Delivery Time :
7days
Name :
4-20mA Digital smart air oil pressure transmitter sensor
Stability :
± 0.10% of URL for 12 months
Output :
RS485/RS232
Measurement Range :
-0.1....0~0.01... ~100MPa
Pressure type :
Gauge, absolute ,sealed gauge
Description

Description:

2088 type pressure transmitter uses piezoresistive silicon oil filled sensor as the signal measuring element. Signal processing circuit located in the stainless steel housing, can convert sensor signal into standard output signal. All the products through components and semi -finished products test, finished products burn-in screening, are with stable and reliable performance. Have strong anti-interference performance, can working in harsh environment conditions for long term.

Specification:

Measurement Range -0.1….0~0.01... ~100MPa
Proof pressure ≤1.5X rated pressure or 110MPa which ever is less
Pressure type Gauge, absolute ,sealed gauge
Accuracy ±0.25%( Typical) ±0.5%( Max.)
Long term stability ±0.2%F.S/year
OperatingTemperatureRange -20℃~80℃
Storage TemperatureRange -40℃~120℃
Power supply 15~30VDC
Output signal 4~20mA 0~10/20mA 0/1~5VDC
Pressure port M20×1.5 or customize
material 1Cr18Ni9Ti stainless steel
Diaphragm material 316L
O-ring Fluororubber
Electrical housing Cast aluminium alloy(2088housing)
Insulation resistance 100MΩ,100VDC
Protection IP65

Detailed Images:

Features:

Wide Range, Explosion-Proof Housing:

The transmitter offers a wide measurement range and is housed in an explosion-proof enclosure, ensuring safe operation in hazardous environments.

Multiple Pressure Ports, Adjustable Output Signals:

With various pressure port options, the transmitter can be easily installed and adapted to different systems. It provides adjustable output signals, allowing for flexibility and compatibility with diverse requirements.

Multiple Protection, Strong Anti-Interference:

Equipped with multiple protection features, the transmitter ensures reliable operation and robust resistance to interference, ensuring accurate and stable measurements.

Marking: ExiaIICT6:

The transmitter is marked with ExiaIICT6, certifying its compliance with explosion-proof standards for use in potentially explosive environments.

Selection Guide:

2088XX
Pressure range -0.1. . .0~0.01...100MPa
(0-X)KP Or MPa X:Measurement range
Code Power supply
D1 24VDC
D2 5VDC
D3 Others
Code Output signal
S1 4~20mADC S5 0~20mADC
S2 1~5VDC S6 0~10VDC
S3 0~5VDC S7 0.5~4.5VDC
S4 0~10mADC
Code Pressure Port
J1 M20×1.5 male
J2 G1/2 male
J3 G1/4 male
J4 7/16-20UNF Female
J5 Others(such as 50.4flange)
Code Electrical connection
B1 Big Din
B2 PG7 PIN
B3 Cable with 1.5 meter
B4 2088 industry housing
B5 2088 housing with LED
B6 others
Code Pressure type
G Gauge
A Absolute pressure
S Sealed pressure
