Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Accuracy 0.1 TUF-2000H Handheld Flow Meter LCD Screen Battery Power
Specifications
Brand Name :
Yunyi
Model Number :
TUF2000H
Certification :
ISO CE
Place of Origin :
China
MOQ :
1
Price :
USD$426-USD$498/Unit
Payment Terms :
T/T, Western Union ,paypal
Supply Ability :
1000 unit/month
Delivery Time :
5-8 working days
Packaging Details :
Standard export package
Model :
TUF2000H
Flow rate range :
± 32m / s
Pipe size :
15mm ~ 6000mm
Cumulative unit :
7 positive, negative and net totalizer
Display :
4 × 8 or 4 × 16 English Chinese
Dimensions :
210 × 90 × 30mm
Weight :
500g (1.2 lbs) including battery
Repeatability :
0.2%
Description

Description of TUF 2000H Hand Held Flow Meter
The TUF-2000H flow meter can be virturally applied to a wide range of measurements. A variety of liquid applications can be accommodated: ultra-pure liquids, potable water chemicals, raw sewage, reclaimed water, cooling water, river water, plant effluent, etc. Because the instrument and transducers are non-contactiong and have no moving parts, the flow meter can not be affected by system pressure, fouling or wear. Standard transducers are rated to 110degree. Higher temperatures can be accommodated. For further information please consult the manufacturer for assistance.


Features of TUF 2000H Hand Held Flow Meter
Precision measurement
Small size, light weight
Non-contact measurement
Large measuring range
Charging Power
Large-screen LCD
Built-in data logger Parameters:

Parameters of TUF 2000H Hand Held Flow Meter

Linearity 0.5%
Repeatability 0.2%
Accuracy Better than ± 1%, the flow rate of > 0.03m / s
Response time 0 to 999 seconds , the user optional
Flow rate range ± 32m / s
Pipe size 15mm ~ 6000mm
Units of measurement Meters, feet , cubic meters, liters, cubic feet , U.S. gallons , UK gallons , barrels , U.S. liquid barrels, barrels of liquid Britain ,U.S. trillion gallons , the user-specified units
Cumulative unit 7 positive, negative and net totalizer
Liquid species Various single uniform conduction of ultrasonic energy in a liquid
Safe sex Lock settings , changing data to be unlocked
Show 4 × 8 or 4 × 16 English Chinese
Communication Interface RS-232, baud rate 75-57600 , also compatible with Fuji ultrasonic flowmeter, the user's requirements should also be compatible with other products
Sensor Standard for the M1 -type , while the other four kinds to choose from
Sensor cable Standard 5m × 2, can also be extended to 10m × 2
Power source 3 AAA Ni-H built-in battery is fully charged each work 12 hours a sustainable , AC100V-240V adapter
Data records Built-in data logger can record 2000 lines of data
Manual Totalizer 7 , the key to start for calibration
Case Material Flame retardant ABS
Dimensions 210 × 90 × 30mm
Weight 500g (1.2 lbs) including battery

FAQ

Q: How long will you reply me?
A: We will contact you as soon as possible but within 12 hours.

Q: Can I get some samples?
A: Yes, Sample order is available for quality check and market test. But you have to pay the express cost.

Q: How soon can you arrange your production?
A: Once getting your product confirmation and receiving the prepayment, the production will be started immediately.

Q: What's delivery time?
A: It usually takes about 3-5 working days for small order and 10-15 days for big order.

Q: How do you control your quality ?
A: Three inspection steps(of original, production, and finished goods) + good warranty service(1 year free to change a new one without any human damage factors).

Q: What certificates do you have ?
A: ISO9000, CE, Explosion-proof certification, RoHs ready. And before the delievry of goods, quality and safety inspection certification issued by third parts also can be offered.

Q: Could I visit your factory?
A: Very welcome! Fly to Xian Yang air port. It was a big pleasure for us.

Q: What's your warranty terms?
A: We offer 12 months warranty time.

Q: Can you provide OEM & Customized service?
A: Yes, OEM and ODM are both available, we have the professional R&D dept which can provide professional solutions for you.
