Flow Meter Magnetic Electromagnetic Flowmeter

The electromagnetic flow meter is an optimal solution for the measurement of conductive fluids in sanitary environments. With a design that eliminates moving parts, this flow meter guarantees a prolonged lifespan while avoiding pressure loss or fluid blockages during operation.

What sets this flow meter apart is its exceptional measurement accuracy, which remains unaffected by the physical properties of the fluid being measured, such as temperature, viscosity, density, and pressure. It can be customized with various lining and electrode materials to accommodate different media requirements.

Offered in pipeline and insertion models, the DN40 flow meter provides installation flexibility and utilizes EEPROM memory for secure storage of data. It is available in integrated and separate configurations, with a high-definition LCD backlit display for readability.

Utilizing Faraday's law of electromagnetic induction, this flow meter accurately measures the volume flow of conductive fluids, making it suitable for applications in industries such as chemical, papermaking, food processing, textile, metallurgy, environmental protection, and water supply and drainage. It can also be seamlessly integrated with computer systems for advanced control capabilities.

Specification of Flow Meter Magnetic Electromagnetic Flowmeter DN40 Sanitary Clamped Milk Beer Flow Meter

Feature of Flow Meter Magnetic Electromagnetic Flowmeter DN40 Sanitary Clamped Milk Beer Flow Meter

1. The measurement results have nothing to do with physical parameters such as flow velocity distribution, fluid pressure, temperature, density, viscosity, etc.
2. The multi-electrode design further ensures the measurement accuracy.
3. There are no moving parts and no blocking parts in the pipeline, and there is almost no additional pressure loss in the measurement.
4. High-definition backlit LCD display, full Chinese menu operation, easy to use, simple to operate, easy to learn and understand.
5. The converter core adopts high-speed central processing unit, which has fast operation speed, high precision, and low-frequency rectangular wave excitation, which improves the stability of flow measurement and low power consumption.
6. Full digital processing, strong anti-interference ability and high measurement accuracy.
7. Ultra-low EMI switching power supply, using a wide range of power supply voltage changes, good EMC resistance.
8. Using EEPROM memory, there is a non-power-off clock inside, which can record the power-off time, and store the measurement and operation data to protect the safety.
9. Two-way measurement system, which can measure forward flow and reverse flow.
10. Password lock function, after the flowmeter is powered on, if you set parameters, you must enter a password to operate.
11. The converter has a self-diagnosis alarm output function, and an empty load detection alarm output.
12. Plug-in structure, simple installation, no need to cut off the flow, can be installed with pressure openings (below 1MPa) on site, economical and convenient, suitable for measuring the flow of large and medium-diameter pipelines.
13. Small signal cut-off function, the user can cut off the disturbing small flow through the display panel settings
14. Zero self-calibration to eliminate zero drift.

Application of Flow Meter Magnetic Electromagnetic Flowmeter

The working principle of the Flow Meter Magnetic Electromagnetic Flowmeter DN40 Sanitary Clamped Milk Beer flow meter is based on Faraday's law of electromagnetic induction. This flowmeter consists of two electromagnetic coils that generate a constant or alternating magnetic field. When a conductive medium, such as milk or beer, flows through the flowmeter, it cuts across the magnetic field lines, inducing a measurable electromotive force detected by two measuring electrodes. The magnitude of this induced electromotive force is directly proportional to the flow rate of the conductive medium, the magnetic field's induction intensity, and the diameter of the pipe being measured. By calculating these factors, the flow rate of the medium can be accurately determined. This principle allows for precise measurement and monitoring of flow rates in a wide range of industries, making electromagnetic flowmeters a popular choice for various applications.

Detaild picture of Flow Meter Magnetic Electromagnetic Flowmeter DN40 Sanitary Clamped Milk Beer Flow Meter
