AXF025 Yokogawa AXF Magnetic Integral Remote Digital Fuel Flow Meter
AXF025 Yokogawa AXF Magnetic Integral Remote Digital Fuel Flow Meter
Specifications
Brand Name :
Yokogawa
Model Number :
AXF025
Place of Origin :
Japan
MOQ :
1 -100
Price :
negotiable
Payment Terms :
T/T
Delivery Time :
7 work days
Place of Origin: :
Japan
Brand Name: :
Yokogawa
Model Number: :
AXF025
Quality: :
Original
guarantee: :
1 year
Accuracy : :
±0.05%
output : :
4 to 20mA DC
Description

Yokogawa AXF Magnetic Integral Remote Digital Fuel Flow Meter

Product Description:

The ADMAG AXF is the magnetic flow meter which has adopted the proven Dual Frequency Excitation. Moreover, the Enhanced Dual Frequency Excitation has been newly added to tackle more severe applications. The AXF has user-friendly functions; such as an electrode adhesion level diagnosis function, infra-red switches which can be used for setting parameters without opening the case cover, ability to change the direction of electrical connection on the site. Based on FOUNDATION™ fieldbus specifications, AXF Fieldbus models offer more flexible instrumentation through a higher level communication capability and propose the cost reduction by multi-drop wirings with less cables. FOUNDATION™ fieldbus is a registered trademark of Fieldbus FOUNDATION. Note: The "Dual Frequency Excitation Method" is a Yokogawa innovation.

Specification:

AXF
Remote Flowtube		 AXF
Integral Flow meter		 AXFA14
Converter		 AXFA11
Converter
Size 2.5 to 400 mm
(0.1 to 16 inch)
[depends on specifications]		 2.5 to 400 mm
(0.1 to 16 inch)
[depends on specifications]		 Combined with Remote type flowtube
2.5 to 400mm
(0.1 to 16 inch)		 Combined with Remote type flowtube (Note)
2.5 to 1800 mm
(0.1 to 16 inch)
Type of Use General-purpose use,
Ex-proof type,
Sanitary type,
Submersible type		 General-purpose use,
Ex-proof type,
Sanitary type		 General-purpose use,
Ex-proof type		 General-purpose use
Fluid Temp. -40 to 160 deg.C
(-40 to 320 deg.F)
[depends on specifications]		 -40 to 130 deg.C
(-40 to 266 deg.F)
[depends on specifications]		 - -
Ambient Temp. -40 to 60 deg.C (-40 to 140 deg.F) [depends on model type]
Accuracy 0.35% of rate (Optional ; 0.2% of rate)
Fluid Conductivity 1 micro-S/cm or larger (depends on nominal pipe size and fluid condition)
Lining Fluorocarbon PFA/Ceramics/Polyurethance Rubber/ - -
Natural Soft Rubber [depends on model type]
Process Connection Wafer, Flange, Sanitary connections
(Clamp[Tri-clamp, DIN, ISO], Union thread[DIN, ISO SMS], Butt-weld), etc.		 - -
Maximum Cable Length - - 100m (330 ft) 200m (660 ft)
Indicator - Multi line backlit LCD (Full dot-matrix)
Diagnosis Adhesion diagnosis, Empty pipe, Coil open, etc.
Alarm message Alarm message with corrective measures is indicated (English, German, French, Italian, Spanish, Japanese)
Excitation method Dual Frequency Excitation: AXF sizes 2.5 to 400 mm,
Enhanced Dual Frequency Excitation (optional): AXF sizes 25 to 200 mm
Pulsed DC Excitation: AXW sizes 500 to 1800 mm (Note)
Ex-proof type ATEX, FM, CSA, IECEx, TIIS -
Options Replaceable electrode, Rotatable terminal box(converter), Mirror finished lining surface(for PFA/Ceramics), Special gaskets, etc.

Good Service:

> Please send your RFQ to get the latest price.
> We will ship the items within 3-5 working days after receive the payment.
> We can ship to you by UPS/DHL//EMS/Fedex. Please contact us and we will use your preferred ways.
> We have a large stock and the prices are variable, so we have good price. If needed, please contact us for specific prices.
