CCY17Y Liquid Differential Pressure Transmitter For Flow Measurement
CCY17Y Liquid Differential Pressure Transmitter For Flow Measurement
CCY17Y Liquid Differential Pressure Transmitter For Flow Measurement
CCY17Y Liquid Differential Pressure Transmitter For Flow Measurement
CCY17Y Liquid Differential Pressure Transmitter For Flow Measurement
CCY17Y Liquid Differential Pressure Transmitter For Flow Measurement
CCY17Y Liquid Differential Pressure Transmitter For Flow Measurement
CCY17Y Liquid Differential Pressure Transmitter For Flow Measurement
Specifications
Brand Name :
Star merter
Model Number :
CCY17Y
Place of Origin :
China
MOQ :
1PC
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
30000 Piece/Month
Range :
0~2.5MPa (see range selection table for details)
Output :
4~20mA, RS485, 0~10VDC, 0~5VDC, 1~5VDC, 0.5~2.5VDC
Power supply :
9~36VDC, 15~36VDC, 3~5VDC
Accuracy :
0.25%FS, 0.5%FS
Name :
Differential Pressure Transmitterf
Description

CCY17Y Differential Pressure Transmitter Industrial Equipment Pharmaceuticals And Biotechnology Flow Monitoring

The CCY17 differential pressure transmitter is designed for industrial applications to measure the differential pressure value of liquids or gases, is not only compact, but also of excellent quality, ideal for general industry, and cost-effective.
It also has diversified advantages such as output signal, range and electrical connection, which is convenient to match different working conditions.

Base parameters
Measuring medium Liquids, fluids, gases (compatible with contact materials)
Pressure mode Differential pressure
Media temperature -40～85℃
On-time 20ms
Accuracy class 0.25%FS (differential pressure range to rated range ratio ≥1:2.5) 0.5%FS (differential pressure range to rated range ratio <1:2.5) With repeatability≤ 0.05%FS, hysteresis ≤0.05%FS Meter display accuracy 0.5%FS<b15>, digital tube (LED)

display
Note: Reference condition temperature 25~86 °C, Atmospheric pressure 106~45kPa, humidity 75~<>%RH.
Response frequency Analog output≤ 30Hz, digital output≤5Hz
Stable performance ± 0.1% FS/year
Temperature compensation -10～70℃
Temperature drift ±0.01%FS/°C (temperature compensation range) ±0.05%FS/°C (outside temperature compensation range)
Degree of protection IP65 (no display) IP54 (with display) Note: The above protection level refers to the electrical connection is complete
Durable performance 10X10⁶ times (lower range to upper range cycles)
Overall weight No display≈ 415g Yes display≈460g
resolution Analog output 0.01%FS, digital output 0.05%FS
Output power
Power supply range 9～36VDC 15～36VDC 3～5VDC
Current type ≤0.02Us(W)
Maximum power
4-20mA Yes/No Display≤0.02Us(W)
RS485 With display ≤0.02Us(W), no display ≤0.015Us(W)
0～10VDC With display ≤0.02Us(W), no display ≤0.008Us(W)
0～5VDC With display ≤0.02Us(W), no display ≤0.008Us(W)
1～5VDC With display ≤0.02Us(W), no display ≤0.008Us(W)
0.5～2.5VDC No display≤0.001Us(W)
Load characteristics
Voltage type ≥10kΩ
Current type No display load≤ {(Us-7.5)÷0.02}Ω with display load≤{(Us-12)÷0.02}Ω (US=supply voltage)
Environmental conditions
Ambient temperature -40～85℃
Ambient humidity 0%~95%RH(no condensation, no condensation)
Overall material
diaphragm 316L stainless steel (contact with the medium to be measured)
Process connection 304 stainless steel (contact with the medium to be measured)
enclosure 304 stainless steel
Seals Nitrile rubber O-ring
Display the shell ABS Engineering Plastics (LED Display)
Hirschman plug ABS engineering plastics
Mechanical stability
Seismic performance 10g(20… 2000Hz) conforms to IEC60068-2-6 standard
Impact resistance 500g/ms conforms to IEC60068-2-27 standard
Electrical protection
Short-circuit protection perpetual
Anti-polarity protection No damage, but not working
Insulation resistance ≥100MΩ 500VDC
Dielectric strength 500VAC
Output limits
4-20mA 4~20mA
RS485 0~2000
0～10VDC 0.001VDC~10VDC
0～5VDC 0.001VDC~5VDC
1～5VDC 0.001VDC~5VDC
0.5～2.5VDC 0.05VDC~5VDC
Manual
Product Information -Chinese (CN) PDF
Product Information -English (EN) PDF
Installation instructions -Chinese (CN) PDF
Installation instructions -English (EN) PDF
Product selection -Chinese (CN) PDF
Product selection -English (EN) PDF
Protocol -Chinese (CN) PDF
Protocol -English (EN) PDF
