DIP P 25-50 LED Media Facade Robust Structure Long Viewing Distance Effective Sun Protection
DIP P 25-50 LED Media Facade Robust Structure Long Viewing Distance Effective Sun Protection
DIP P 25-50 LED Media Facade Robust Structure Long Viewing Distance Effective Sun Protection
DIP P 25-50 LED Media Facade Robust Structure Long Viewing Distance Effective Sun Protection
DIP P 25-50 LED Media Facade Robust Structure Long Viewing Distance Effective Sun Protection
DIP P 25-50 LED Media Facade Robust Structure Long Viewing Distance Effective Sun Protection
Specifications
Brand Name :
AHL
Model Number :
Ev 25-50
Certification :
CE ROHS
Place of Origin :
China
MOQ :
1 Square Meter
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5,000 square meters per month
Delivery Time :
20-25 day
Packaging Details :
Wooden box or Flight case
Pixel configuration :
1R1G1B
LED type :
DIP 346
Cabinets position :
Vertically/Horizont
Waterproof :
IP67
Description

LED Media Facade

1. RGB Multi-color LED, can mix 256*256*256 kinds of color by DMX controller.
2. Our engineer can help preset flowing,chasing,star shining and so on programs , satisfy your demand.
3. Special material,make the led display/led screen strong used for outdoor.
4. SMPS power supply suitable for every country voltage.
5. With CE & ROHS certificate
6. Installed by snap and steel wire, fixed easy for your demand.
7. Controller:DMX512 &,sound active,slave-master,dimmer,strobe,speed.
8. easy hung the curtain on truss or stands with the spare parts strapping tape. strong connection cable between curtains and controller.

LED Mesh Facade Product features

LED Mesh Facade Specification:

Parameter Specification
Product model EV12 EV15 EV 20 EV15-31 EV25 EV25-50 EV 31
Pixel configuration 1R1G1B
LED type DIP 346
Pixel Pitch(mm) 12.5 mm 15.625 mm 20 mm 15.625/31.25 mm 25 mm 25-50 mm 31.25 mm
Cabinet size(W×H×D) L500×H1000mm L500×H1000mm L520×H1000mm L500×H1000mm L500×H1000mm L500×H1000mm L500×H1000mm
Cabinet resolution(W×H) 40×80 32 × 64 26 ×50 16×64 20×40 10×40 16×32
Pixel density 6400 dots/㎡ 4096 dots/㎡ 2500 dots/㎡ 2048 dots/㎡ 1600 dots/㎡ 800 dots/㎡ 2048 dots/㎡
Cabinets position Vertically Horizont/Vertically Horizont/Vertically Vertically Vertically Vertically Vertically
Transparency level 20% 30% 36% 58% 58% 75% 65%
Brightness ≥4500nit ≥7500nit ≥7000nit ≥6500nit ≥6000nit ≥6000nit ≥6000nit
Weight 25 KG/㎡ 21 KG/㎡ 19 KG/㎡ 16 KG/㎡ 18 KG/㎡ 18 KG/㎡ 18 KG/㎡
Maximun power consumption 480W/㎡ 400W/㎡ 375 W/㎡ 480W/㎡ 480W/㎡ 480W/㎡ 480W/㎡
Average power consumption 160W/㎡ 130W/㎡ 125W/㎡ 160W/㎡ 160W/㎡ 160W/㎡ 160W/㎡
Viewing Angle H100°/V60°
Waterproof IP67
Cabinets width 113mm
Width after install 150mm
Wind resistancy level 12
Fire safety 10S/cabinet
Service method Front & rear
Scanning Static
White balance 3200-9300K
Frame-changing frequency 60Hz
Working temperature -40℃- 60℃
Storage temperature -55℃120℃
Life time ≥100,000 hours
Input voltage(V) AC110-220V
Grey scale 16bit

Application scopes

widely applied to the outdoor advertisement, stage shows, advertising screes, concerts, stadium display screen and so on.

Product Description & Features & advantages:

1. Our service:

  • Reply immediately.
  • Quickly quote within 12 hours.
  • Best solution offered according to your needs
  • Big support from our company and responsible sales for after-sale service.
  • Our competitors say: "We won’t be beaten on price.".We would rather say: "We will not be beaten on quality"

2. Brief introduction:

  • High Portability with strong water and wind resistance.
  • High stability of both screen and image performance, with Integrated light bar structure..
  • High protection level: IP65.
  • High: Brightness keeps continuously work for 96 h even in a harsh place.
  • Font and rear maintenance.


3. Main application:

  • Outdooroversize building facade, glass LED video wall, transparent LED curtain facade.
  • Fixed installation.
