High Output Fruit And Vegetable Processing Line Pineapple Juice Processing Plant
High Output Fruit And Vegetable Processing Line Pineapple Juice Processing Plant
High Output Fruit And Vegetable Processing Line Pineapple Juice Processing Plant
High Output Fruit And Vegetable Processing Line Pineapple Juice Processing Plant
Specifications
Brand Name :
Triowin
Model Number :
Pineapple Processing Line
Certification :
CE ISO
Place of Origin :
Shanghai, China (Mainland)
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
99 Unit/Units per Year
Delivery Time :
120days
Packaging Details :
Export standard package
Voltage :
380V
Weight :
according to model
Dimension(L*W*H) :
customized
Power(W) :
200KW
After-sales Service Provided: :
Engineers available to service mac
Raw material :
Fresh Pineapple
Processing capacity :
From 60tons/day to 2000 tons/day
Description

Pineapple Juice Processing Plant Fruit And Vegetable Processing Line canned

Description of Pineapple Juice Processing Plant

High quality products and services have positioned Triowin as the Chinese market leader in pineapple juice processing equipment. Since China ranks the biggest concentrated pineapple juice producer in the worldwide market, Triowin has created a pineapple processing segment that provides all of the necessary processing machinery for achieving quality products at controlled cost.

Triowin's fruit reception lines are designed to satisfy the most rigorous standards of hygiene in cleaning the raw material. Then highly sophisticated mills ensure optimized mash preparation. Featuring a unique drainage system, the Triowin Belt Press with an optimizing control system gives a maximum yield of top quality juices with very low sediment content.

Equipped with ultrafiltration system, membrane filtration systems produce clear and stable juices. Adsorption and ion exchange systems allow further purification of liquid foods, while Triowin's multistage vacuum evaporators come with sterilization and aseptic filling unit. To assure outstanding ease and reliability of operation, we also provide an electronic monitoring and control system. And to round off the range of high-tech machines, we offer comprehensive engineering services, installation supervision, commissioning support and operator training.

Features of Pineapple Juice Processing Plant

* Capacity varies from 3tons/day to 50tons/day.
* Mango/pineapple juice,jam,canned machine can be provided
* Fresh and frozen fruit can be processed
* Pneumatic press type with nitrogen protection to produce high yield quality juice preventing from oxidation.
* Pasteurizing method can keep the original fruit color and aroma
* Through enzymolysis and ultrafiltration to produce clarified juice products.
* The whole line features high automatic degree, saves labor power.

Specification of Pineapple Juice Processing Plant

Raw material Fresh Pineapple
End product Concentrated juice, clear juice
Processing capacity From 60tons/day to 2000 tons/day
Efficient input 75% raw fruit (25% as waste,peels and seeds)
Fruit consistence 10-12Brix
Product consistence 70~72Brix for concentrated juice
End package Aseptic bag/tin can/glass bottle/PET bottle
Output Can be calculated

Flow Chart of Pineapple Juice Processing Plant

High Output Fruit And Vegetable Processing Line Pineapple Juice Processing Plant

Type of End Product

High Output Fruit And Vegetable Processing Line Pineapple Juice Processing Plant
