12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
Specifications
Brand Name :
LIYUE
Model Number :
SQ12A4 SQ12A5
Certification :
CE
Place of Origin :
Henan, China
MOQ :
1
Price :
$21,400.00/units 1-2 units
Supply Ability :
3000 Unit/Units per Year
Packaging Details :
Nude packing
Feature :
TRUCK CRANE
Showroom Location :
Indonesia
Condition :
New
Application :
Construction
Rated Loading Capacity :
12 ton
Rated Lifting Moment :
5.15-15 T.M
Max. Lifting Height :
17.2 m
Span :
2270-5270 mm
Warranty :
1 Year
Hydraulic Cylinder Brand :
MOOG
Hydraulic Pump Brand :
Changjiang
Hydraulic Valve Brand :
Liyuan
Engine Brand :
YUNNEI
UNIQUE SELLING POINT :
High operating efficiency
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Core Components :
Bearing, Pump
Weight (KG) :
4316 kg
Product name :
Truck Mounted Crane
Crane type :
Truck Crane Mobile Crane Hydraulic Crane
Hydraulic parts :
Famous Brand Hydraulic Parts
Capacity :
12 Ton Truck Crane
Boom type :
Hydraulic Straight Arm
Color :
Customer Requirements
Usage :
Construction Lifting
Rotation Angle :
360 Degree
Installation space :
1300 mm
High quality :
Mobile Crane Lifting Capacity
Description

12ton Construction Telescopic Boom Truck Mounted Crane

NOTE: The price is for crane part only.
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
SPECIFICATIONS FOR 12 TON CRANE TRUCK
Crane Dimension
Model
-
SQ 12T
Max. Lifting Capacity
kg
12000
Max. Lifting Height
m
17.2
Working Radius/ Span
m
2.5- 13.5
Rotation Angle
º
360
Boom Elevation
º
3-75
Boom Sections
Pcs
4
Outrigger Span (Fully Extended)
mm
2270-5270
Crane Weight
kg
4316
Hydraulic Tank Capacity
L
160
Max. Flow Rate of Hydraulic Oil System
L/min
63
Hydraulic System Rated Pressure
Mpa
26
Installation Space
mm
1300
Working Parameter
The Basic Boom Length
m
5.15-15
Max. Lifting Torque
T.m
30
Max. Slewing Speed
r/ min
2
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
Product Show
Product Show
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

Product Process

Famous Brand Hydraulic Parts for our Truck Crane

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

Prodution Progress

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

Packing & Shipping

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

Client Visit

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

Certifications

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

Optional Device

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

Foreign Cases

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

Related Products

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span

customer evaluation

12 Ton Hydraulic Truck Crane With 4 Boom Sections And Fully Extended Outrigger Span
