12v Esd Tvs Diode Chip Transient Voltage Suppression Diode Bidirectional

Specifications

Brand Name :

trusTec

Model Number :

SM8S10A

Certification :

ROHS

Place of Origin :

China

MOQ :

0.75K PCS

Price :

Negotiable (EXW/FOB/CNF)

Payment Terms :

T/T

Supply Ability :

800KK PCS per month

Delivery Time :

10 work days fresh products

Packaging Details :

0.75K PCS per tape&reel, 4.5K PCS per carton.

Stand-off Voltage :

10V

Power :

6600W

Package :

DO-218AB

Type :

SMD TVS Diode

Package Type :

Surface Mount

Packing :

Tape&Reel

Material :

Silicon

Craft :

GPP

Description

12v Esd Tvs Diode Chip Transient Voltage Suppression Diode

Our company:

Changzhou Trustec is professional manufacturer and supplier of semiconductor diodes.

Main products include standard silicon rectifier diode, fast recovery rectifier diode, high efficiency rectifier diode, ultra fast recovery rectifier diode, super fast recovery rectifier diode, small signal high speed switching diode, schottky barrier rectifier diode, zener diode, TVS, DIAC, various bridge rectifier etc.

Product Description

SM8SxxxXX Series transient voltage suppressors are excellent overvoltage protective devices.

The Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Product Features

Surface mount package

Excellent clamping capability

Glass passivated junction

Fast response time: Less than 1 ns forUni-direction, From 0 Volts to BV min

Plastic material has UL flammability classification 94V-O

RoHS compliant in lead-free versions

Ideally suited for load dump protection

High temperature stability

Integrally molded heatsink provides a very low thermal resistance for maximum heat dissipation

Low leakage current

High temperature soldering guaranteed: 260°C for 10 seconds at terminals

Low forward voltage drop

Electrical Characteristics

Type	Power	Package
SMAF5.0A THRU SMAF170A	200	SOD-123FL
SMAF5.0CA THRU SMAF170CA	200	SOD-123FL
SMAJ5.0A THRU SMAJ440A	400	SMA
SMAJ5.0CA THRU SMAJ440CA	400	SMA
SMBJ5.0A THRU SMBJ440A	600	SMB
SMBJ5.0CA THRU SMBJ440CA	600	SMB
SMCJ5.0A THRU SMCJ440A	1500	SMC
SMCJ5.0CA THRU SMCJ440CA	1500	SMC
SMDJ5.0A THRU SMDJ220A	3000	SMC
SMDJ5.0CA THRU SMDJ220CA	3000	SMC
5.0SMDJ12A THRU 5.0SMDJ170A	5000	SMC
5.0SMDJ12CA THRU 5.0SMDJ170CA	5000	SMC
SM8S10A THRU SM8S43A	6600	DO-218AB

Mechanical Characteristics

Case: DO-218AB Molded plastic body, surface mount with heatsink integrally mounted in the encapsulation

Terminals: Plated, solderable per MIL-STD-750, Method 2026

Polarity: Heatsink is anode Mounting

Position: Any Weight: 0.091 oz., 2.58 g

Rating And Characteristic Curves

12v Esd Tvs Diode Chip Transient Voltage Suppression Diode Bidirectional

Product Applications

Telecom

Computer

Industrial electronic

Consumer electronic
