CNAS TFT Touch Screen 75 Inch Interactive Touch Monitor Windows 10
CNAS TFT Touch Screen 75 Inch Interactive Touch Monitor Windows 10
Specifications
Brand Name :
TSINGHILL
Model Number :
TH75
Certification :
CE ROHS FCC CCC ISO9001 CNAS
Place of Origin :
Beijing, China
MOQ :
1 Unit
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100,000 Units per Month
Delivery Time :
5-30 days
Packaging Details :
Honeycomb Box
Panel Size :
75 inch
Display Dimension :
1650.24mm*928.26mm
Operating System :
Windows 7/Windows 10/Android
Panel Type :
TFT
Widescreen :
Yes
Description

Wholesale 75 Inch Smart Interactive Nano Blackboard Magnetic Smart Board

Product Specifications:

Smart Nano Blackboard Specifications
Model TH75
Size 75 inch
PanelBacklight D-LED(OD28)
Display Dimension 1650.24mm*928.26mm
Resolution 3840*2160
Glass chalk, liquid chalk and marker
Thickness of glass 3mm
Hardness Mhos 7H
Features Black, Reversible, double-sided writing
Brightness 16:09
Ratio 4000:1 Typ.
Contrast 400nit (without glass), 350nit (with glass)
View angle 8ms(Typ.)12ms(Max.)
Response time 10 Bit (1.07B)
Touch
Type Capacitive touch
Technology Nano Touch
Active area 1654.24mmx932.1mm
Interface USB2.0/3.0
Operate system Win7, 8.1, 10/Android
Touch point 20 points in windows, 10 points in Android
Linearity ±2.5
Working current < 500mA
Stand-by current 1A
Working voltage DC5V
Maninboard
Model ADV811
Android version Android 11.0 64Bit
Chip type Hi3751ARBCV8110D0N
CPU Dual-core A73 and dual-core A53 ,1.5GHz
GPU Quad-core MaliG51
RAM 4GB DDR4
Flash 32GB (64GB optional)
Interface
Type-C, HDMI OUT, HDMI IN, USB 2.0, USB3.0, VGA IN, DP, RS232, RJ45 IN, OPS SLOT, SPDIF OUT, Touch USB, Earphone, MIC
Basic Info.
Gross weight 98.27(KG)
Net weight 85.1(KG)
Panel dimension(W x D x H) 1991.1mm*93.5mm*1201.0mm
Blackboard dimension(W x D x H) 986.0mm*17.5mm*1201.0mm

Features and Parameters:

1.Nano intelligent blackboard, the combination of traditional blackboard and multimedia teaching equipment to create a new interesting and interactive teaching mode.

2.The ultra-thin body, delicate and beautiful (with a patent certificate for appearance) and thoughtful design of rounded corners provide safe and reliable escort for students.

3.Micro magnetic high hardness aluminum honeycomb attached board, surface hardness of 8H writing on the board clear and smooth, erase, clean the writing without leaving a mark.

4.Front functional interface, support Word, Excel, PPT, PDF, video, picture, music and other document formats.


5.AG anti-glare tempered glass, double screen explosion-proof, safe and durable.

6.4K HD display, 178° wide viewing Angle, does not affect the outside two rows of students to watch the blackboard content, zero bonding technology, waterproof and dust-proof.

Product Features:

CNAS TFT Touch Screen 75 Inch Interactive Touch Monitor Windows 10CNAS TFT Touch Screen 75 Inch Interactive Touch Monitor Windows 10

About TSINGHILL:

Guangdong TSINGHILL Technology Co., Ltd, founded in 2016, is a national high-tech enterprise, possessing core patents and an independent R&D team. We can provide customers with personalized OEM, ODM solutions. Our main markets are North America, Europe, Russia, the Middle East, Southeast Asia, mainland China and more.

TSINGHILL is a high-tech enterprise engaged in the development, manufacturing and sales of digital intelligent products for 8 years. It's focus on interactive flat panel display area. And main applicant in education, conferencing, government, hospitality, digital signage, and similar environments.
