MTRJ LC Single Mode Fibre Connectors For Female / Male Cable
MTRJ LC Single Mode Fibre Connectors For Female / Male Cable
MTRJ LC Single Mode Fibre Connectors For Female / Male Cable
MTRJ LC Single Mode Fibre Connectors For Female / Male Cable
Specifications
Brand Name :
TTI
Model Number :
FOC-MTRJ
Certification :
ISO, SGS, ROHS
Place of Origin :
China
MOQ :
10 pcs
Price :
Negotiation
Payment Terms :
T/T, , PayPal
Supply Ability :
8000 pcs/day
Delivery Time :
2-3 days
Packaging Details :
PE bag
Connector Type :
LC
Ferrule End-face :
PC, UPC,APC
Fiber Type :
Singlemode, Multimode
Cable Type :
Duplex
Cable OD :
2.0
Housing material :
plastic
Insertion Loss :
<0.3dB
Return Loss :
>50dB(SM), >35dB(MM)
Description

MTRJ Single mode Fiber Optic Connector for Simplex / Duplex Cable

Description:

MT-RJ is a duplex fiber connector with both fibers in a single polymer ferrule.

It uses pins for alignment and has male and female versions. Multimode only, field terminated only by prepolished/splice method.

Features:

Ceramic Ferrule

High return loss

Low insertion loss

Good repeatability and and exchangeability

Excellent Polished and 100% tested

Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard

Application:

Local Area Network (LAN)

Data communication network

Telecommunication optical transmission network

Optical access network(OAN)

Active device termination

Fiber optics data transmission(FODT)

Test Equipment

Specification:

Item Single Mode Multi Mode
Insertion Loss ≦0.2dB ≦0.3bB
Insert-Pull Test 1000 times
Operating Temperature -40°C ~ +85°C
Ceramic Ferrule Specification 125.5um concentricity deviations:≦1um 127um concentricity deviations:≦3um
Suitable Fiber 9/125um 50/125um,62.5/125um
Order Information:
Item Connector Description Item Connector Description
PC/UPC/APC PC/UPC/APC
Connector Singlemode 9/125 ST Connector Multimode (50/125 or 62.5/125) ST
SC SC
FC FC
LC LC
MU MU
MTRJ(female) MTRJ(female)
MTRJ(male) MTRJ(male)
DIN


Product Picture:

MTRJ LC Single Mode Fibre Connectors For Female / Male Cable
