APC Duplex Fiber Female Female Adapter With Green Color Housing , SC Shape Type
APC Duplex Fiber Female Female Adapter With Green Color Housing , SC Shape Type
APC Duplex Fiber Female Female Adapter With Green Color Housing , SC Shape Type
APC Duplex Fiber Female Female Adapter With Green Color Housing , SC Shape Type
APC Duplex Fiber Female Female Adapter With Green Color Housing , SC Shape Type
APC Duplex Fiber Female Female Adapter With Green Color Housing , SC Shape Type
Specifications
Brand Name :
TTI/OEM/ODM
Model Number :
LC-Quad
Certification :
ISO, SGS, ROHS
Place of Origin :
China
MOQ :
25pcs
Price :
Negotiation
Payment Terms :
T/T, L/C, , PayPal
Supply Ability :
500000pcs/month
Delivery Time :
2~3 days
Packaging Details :
Plastic bag
Connector Type :
LC-LC-APC
Mode :
Singlemode, Multimode
Type :
Simplex, Duplex, Quad
Sleeve :
Zirconia/Ceramic, Copper
Housing :
ABS, PBT, PC
Color :
Blue, Beige, Green, Customized
End-face :
PC, UPC, APC
Structure :
Female to Female
Description

APC Duplex Fiber Optic Adapter with Green Color Housing , SC Shape Type

Single-mode and multimode LC adapters come with a choice of zirconia ceramic or phosphor bronze split sleeves, including zirconia diagonal split sleeves for PC and APC applications.

The LC Adapters were developed by Lucent Technologies. They are composed of a plastic housing with an RJ45 push-pull style clip.

Features:

Excellent mechanical capability

Variety of colors

Low insertion loss value

Choice of housing and sleeve materials

Stable capability and high reliability

Application:

Local area networks

Wide area networks

Data processing networks

CATV

Telecom networks

Optical test equipments

Parts &Material:

Parts

Material

Remarks

Sleeve

Zirconia, PB

Housing

PC

Flammability UL94 V-0

Dust cap

PVC

Flammability UL94 V-0

Clip

stailess steel

Optical Performance:

Item

Premium Grade

Standard Grade

Insertion Loss

≤0.1dB

≤0.2dB

Durability

1000 times

1000 times

Environment and Mechanical:

Properties

Test condition

Conformance

Test result

Vibration

10-55Hz, 1.5mm, 60min

IEC61300-2-1

≤0.2dB

Mating Durability

1000 Mating, clean every 25 mating.

IEC61300-2-2

≤0.2dB

Impact

1.5m, 8 drops

IEC61300-2-6

≤0.2dB

Strength of Coupling Mechanism

40N, 10Min, L=22-28cm

IEC61300-2-12

≤0.2dB

Temperature Cycling

40ºC to +75ºC, 40 cycles

IEC61300-2-22

≤0.2dB

Temperature humidty cycling

40ºC, 95%, 96Hr

IEC61300-2-21

≤0.2dB

Operating Temperature

-40ºC to +85ºC

≤0.2dB

Storage Temperature

-40ºC to +85ºC

≤0.2dB


Order Information:

LC/APC-LC/APC-SM-DX-ABS
1. Connector Type: FC, SC, LC, ST, MPO, MTRJ, MU,D4, DIN, SMA
2. Ferrule End-face: PC, UPC, APC
3. Core Type : SM, MM(OM1 OM2 OM3 OM4)
4. Structure: Simpled, Duplex, Quad
5. With flange, without flange
6. Sleeve: copper alloy,Zinc alloy
7. Material: ABS, PC, PBT

APC Duplex Fiber Female Female Adapter With Green Color Housing , SC Shape Type
