PLC Control NC Tube Bending Machine High Speed Oil Pressure Bending NC100
PLC Control NC Tube Bending Machine High Speed Oil Pressure Bending NC100
Specifications
Model Number :
NC100
Place of Origin :
China
Brand Name :
YUANTAI
Certification :
CE
MOQ :
1 set
Price :
Negotiatable
Packaging Details :
Standard export wooden case or pallet package
Module No. :
NC100
CNC/NC :
NC
Precision :
±0.15°
Max Bending Speed :
20°/sec
Application :
Construction Projects
Machine Type :
Pipe and Tube Bending Machine
Description

NC100 Tube bender

  • Bending part automatic
  • Equipped with hydraulic system--economical way
  • Stable performance
  • Easy operation
  • Cost-effictive machine

technical parameter technical parameter NC100
Max capacity round tube/Iron tube Φ101.6x5.5t
( S=40kgf/mm ² )
Round Tube/Non iron metal Φ101.6x10.0t
( S=25kgf/mm ² )
Round tube/stainless steel tube Φ101.6x3.0t
( S=60kgf/mm ² )
Square tube/Metal tube 70x70x5.5t
( S=40kgf/mm ² )
round Bar Φ50
( S=40kgf/mm ² )
Oil pressure bending precision ±0.15°
Max speed 20°/sec

Machine characteristics
(1) Oil pressure bending
(2) Imported electronic component
(3) PLC control
(4) Manual material feeding
(5) Left bending machine need be customized


Advantages:

1, Microcomputer control, machine operation is very stable
2, With manual, automatic, semi-cycle, full cycle and other functions of arbitrary choice
3, 16 angle settings (0-185 degrees arbitrary), either single or two consecutive options
4, Mobile foot switch with three functions: automatic start, emergency stop, tight stop, high safety
5, Large capacity cooling cycle system, make the machine run more stable.
6, Die replacement is simple and convenient for flexible production.
7, The machine head, the tube bending design is exquisite, provides the maximum bend space.

Our Company:

Yuantai (Zhangjiagang) Machinery Technology Co., Ltd. is a leading technology enterprise specializing in the manufacture and development of CNC tube bending machines. Many kinds of CNC tube bender developed by the company are in the leading level at home and abroad and even in the world, reaching the world synchronous leading level.
The company independently developed the full-electric CNC tube bending machine control system is in the industry leading level, and obtained dozens of patents. Advanced techniques such as three-dimensional dynamic information simulation design and finite element force analysis are used in mechanical design.


FAQ

1. How to choose the pipe/tube bending machine?

You have to inform us following details:
- Max. outside diameter
- Wall thickness range
- Bending radius (CLR)
- The pipe material
- The drawings if possible

2. Do you provide any training to make sure our user can operate the machine very well?

1) We will provide detailed video and instruction book for this machine;
2) We also offer training in our factory to all the clients,and we will arrange everything for you during these days in our city,to make sure every client will be the expert in using our machine!

3. How long warranty can you provide?

Our machine warranty is one year,and we use all the stable compoenents with long working life!
And we can also send our technician to do the after-sale service in client's factory!
