Industrial ice flake machine for ice factory
Industrial ice flake machine for ice factory
Specifications
Brand Name :
Icemedal
Model Number :
BF 10000
Certification :
CE
Place of Origin :
Hunan, China
MOQ :
1
Price :
$22,000.00/sets >=1 sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 Set/Sets per Month
Delivery Time :
≤1 Set 35 Days
Packaging Details :
1. Standard wooden case. 2. Completely ice machine we offer that include ice machine, cooling tower, water pump, water pipes and water pipe fittings. 3. All required component
Description

Industrial ice flake machine for ice factoryIndustrial ice flake machine for ice factory

Product Pamameter

Product Parameter
Model Daily Output (T/24h) Cooling method Compressor Power Fan Power for Cooling Tower Cooling Pump Power Unit Size Unit N.W. (KG)
(L*W*H mm)
BF 10000 10 Water 33.8 kw 1.5 kw 4 kw 2500*2000*1860 1500
BF 15000 15 Water 44.5 kw 1.5 kw 4 kw 3350*2150*1960 3200
BF 20000 20 Water 64 kw 1.5 kw 5.5 kw 3400*2220*2230 4200

* Power supply: voltage 380 V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately)

* Operating conditions: T (water supply):20℃, T (ambient): 32℃, T (condensing): 38℃, T (evaporating): -20℃.

Application Industry

Industrial ice flake machine for ice factory

Our Project

Industrial ice flake machine for ice factory

Packaging & Shipping

Industrial ice flake machine for ice factory

Our company

Industrial ice flake machine for ice factory

Certifications

Industrial ice flake machine for ice factory

FAQ

1.Q:I want to build an ice factory. How big the equipment is?

A:This needs to consider the model according to the output of ice you need in a day. The volume and ice ouput of different models are different. Refer to the parameter table on the details page.
2.Q:Where is the best place to install the equipment and what other factors need to be considered?

A:There is no direct sunlight and good ventilation. It is also necessary to consider whether there is water source and stable power supply. The water pipe needs to be large enough and have enough power
3.Q:How to transport and install equipment?
A:After the goods arrive at the port of destination, forklifts need to be arranged, and the machinery is relatively heavy.

we will tested and install well the machine before shipment, all necessary spare parts,operation,manual and CD are provided to guide the installation. We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer.
4,Q:What is the price, what is the daily maintenance, and does it need to be looked after?

A:The prices of various models are different. Please consult the salesman for details. Keep the unit clean and sanitary, and clean the scale of water tank and evaporator from time to time. Check whether the apron pipe of the apron is blocked. There are still many details to pay attention to we will provide the operation manual.
5,Q:How much water and electricity does a ton of ice need?

A;The production cost of flake ice is very economical. It only takes about 85 degrees of electricity to refrigerate 16 ℃ water into 1 ton of flake ice.
