Rectangular Metal Pipe Punching Equipment Closed Loop Control System
Rectangular Metal Pipe Punching Equipment Closed Loop Control System
Specifications
Brand Name :
BST
Model Number :
BST-125-2-CK
Certification :
CE, FDA
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
200 sets/month
Delivery Time :
Around 15-20 working days
Packaging Details :
Seaworthy wooden case packing
Machine type :
Hydraulic pipe punching machine
Function :
Punching on metal pipes and profiles
Cutting device :
Optional
Processing length :
6 meters or customized
Punching surface :
Single side or double sides
Oil tank capacity :
180L
Description

Metal Pipe And Sheet Metal Hole Punching Machine Pipe Punching Equipment

Machine Features

The CNC pipe punching machine is widely used in aluminum alloy doors and windows, stainless steel stair handrail, metal mesh, fence, shelves, zinc steel guardrail, reveal frame, hardware and sanitary ware, dryer, communications antenna frame, furniture, telescopic doors, building accessories, greenhouses, municipal construction, sports equipment, automobile, motorcycle, bicycle, stainless steel decoration products, etc.

It can do any shape of hole punching on round tube, square tube, rectangular tube, angle iron, channel steel, C-shape steel, etc.

Technical Parameter

Automatic CNC pipe punching machine
Model BST-125-2-CK
Hydraulic motor power 11KW
Cylinder specifications 125*100mm
Punching stroke 100mm
Punching force 196Kn
Max. pressure 16Mpa
Punching materials and objects Aluminum, iron, stainless steel, brass, copper, PVC tubes and profiles. Angle iron, C-shape steel, channel steel and other irregular shaped profiles.
Profiles punching size Square tube: Max. 60*60mm (half hole punching), 50*50mm (full hole punching).
Angle iron: Max. L60*60mm. Rectangular tube: Max. 50*100mm.
Punching thickness 0-4.0mm
Power supply 380V-50Hz
Control voltage DC24V
Cooling method Forced air cooling
Control system type Closed loop control system
Punching frequency 0.8-2.0S/Time
Servo system 1KW
Operating system User-friendly touch screen operation
Touch screen 7 inches
Guide rail Linear guide rail
Oil tank capacity 180L
Oil tank inspection port Available
Oil tank drain Quick ball valve type
Working light DC24V-LED working light
Protection System Hydraulic pressure protection, voltage protection, motor phase loss and phase sequence protection, motor overheating protection
Working length 6000mm
Overall dimension 6800*1500*900mm
Machine weight 2.4T

Rectangular Metal Pipe Punching Equipment Closed Loop Control System

Rectangular Metal Pipe Punching Equipment Closed Loop Control System

Samples

Rectangular Metal Pipe Punching Equipment Closed Loop Control System

Application industries

Rectangular Metal Pipe Punching Equipment Closed Loop Control System

Company introduction

Foshan BST Machinery is the first professional company in China which focuses on R&D of pipe punching equipments and moulds. Our company’s products, hydraulic high-speed punching machines and automatic calibration safety moulds, are highly recognized and praised by the industries of stainless steel/ aluminum/ zinc steel fences, guardrails, shelves, furnitures, steel structures, doors and gates, etc.

We also specialize in some other machineries such as fiber laser cutting machine, CO2 laser cutting machine, laser welding machine, laser cleaning machine, laser marking machine, etc.

Rectangular Metal Pipe Punching Equipment Closed Loop Control System

Service

1. Strict quality control procedures: Each production process of BST automatic punching machine must go through in-house inspection and testing, and can only leave the factory after passing strict inspection. BST is very strict on the quality of the equipment, only to make high-quality, excellent and stable automatic punching machines, so that you can get a good experience when using the equipment.

2. Long warranty period: All mainframes of the punching machine produced by BST have one-year warranty.

3. Perfect after-sales service
Service tenet: Fast, decisive, accurate, thoughtful.
Service goal: Service quality to win customer satisfaction.
Service efficiency: If the equipment fails within or not within the warranty period, you can contact us online, and the problem can usually be solved within 2 working hours.
