Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills
Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills
Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills
Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills
Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills
Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills
Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills
Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills
Specifications
Brand Name :
SEEGO CARIBDE
Model Number :
Dia from 0.3-40mm, Length 330mm
Certification :
SGS, CE, ISO
Place of Origin :
CHINA
MOQ :
2kg
Price :
Can be negociated together
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
45Tons/Month
Delivery Time :
5-8 days
Packaging Details :
Plastic Boxes inside + Carton Boxes outside
Material :
100% Virgin Tungsten Carbide
Detailed Product Description :
Sintered Unground Solid Tungsten Carbide Rod
Surface :
Blank or polished, Grinding, Polishing, Sand-blasted
Features :
Good wear resistance, impact resistance, High bending strength
Hardness HRA :
91.5-94.0HRA
Grain size :
0.5um-1.0um
Production Method :
Extrusion/Press/CIP
Grades :
K10/K20/K30/K40/Yl10.2/Yg6/Yg6X/Yg8/Yg10X/Yl10.2
The smallest Dia we made :
0.3mm
The longest length we made :
1000mm
Description

Solid Cut - to - length Tungsten Carbide Rod for PCB Drills and Endmills

Comapny Info:

Zhuzhou Seego Carbide Tools Co., Ltd. is located in the hometown of Chinese carbide industry – Zhuzhou city.

The Company has more than 10 years ‘experience in manufacturing, designing and sales of various kinds of carbide products. Depending on our talented engineers and skillful workers, we always provide our customers the products with good quality, competitive price, fast turnaround and reliable after sales service.

Advantages:

1. HIP sintering + Extrusion + CIP Method to ensure good performance.

2. Most complete production line of grounded Cut-to-length carbide rods for cutting tool blanks in stock!

3. Various grades and types available according to different working environment request.
4. Very good price, discount for large quantity.
5. Fast delivery time.
6. High precision ground, such as h5, h6

7. The smallest Dia we made is 0.3mm with standard length 330mm

8. The longest length we made is 1000mm

Application:

1 For making Varioius drill bits
2 Automobile Special Cutters
3 Printed Circuit Board
4 Special Cutters
5 Engine Special Cutters
6 Milling and Drill Cutter Tools
7 Graver for woodworking and Medicion
8 Endmills, Gun Drills, PCD drills

Series and Speciafications:

►Diameter Size:

Diamter from 0.3mm to 40mm , lenght between 10-1000 mm

(standard length is 330 mm and 310mm)
►Tolerances: Blank/Ungrounded, polish with h6 or h5 tolerances, Customized tolerances are ok

Grade:

Grade ISO
Grade		 Cobalt
%		 Density
g/cm3		 Hardness
HRA
YG8 K30 8 14.8 89.5
YG6 K20 6 14.95 90.5
YG6X K10 6 14.95 91.5
YL10.2 K30 10 14.5 91.8
YG13X K30-K40 13 14.3 89.5
YG15 K40 15 14 87.5

Main Series of the Tungsten Carbide Rods:

Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills

Packing and Delivery:

► Packaging Details:Carton box and inner plastic bag.
► Delivery Detail: Within 10-30 days upon confirm the order.

The Other Three Main Products of our Company are as below:

1- General Tungsten Carbide Products:

Carbide Rods and Plates, Carbide Strips/Bars, Drawing Dies, Cold Forging Dies,Carbide Nozzles and Mining Buttons, etc.

2- Cutting tools:

End Mills, Carbide Drills, Woodworking Tools, Carbide Adaptor Holders, Carbide Burrs, Indexable Inserts, Shims and Substrate Inserts, Woodworking Tools, etc.

3- Nonstandard & Precision Products:

Wire Guides, Gun Drill Tips, Valve Seat and Balls, Carbide Rollers, Circular Cutting Discs, Carbide Blades, Grinding Bushes, Carbide Scraper, etc.

Note: Welcome------customizable for individual requirements.

Solid Cut - To - Length Tungsten Carbide Rod For PCB Drills And Endmills
