Screws Forging Tungsten Carbide Dies , High Strength Carbide Cold Heading Dies
Screws Forging Tungsten Carbide Dies , High Strength Carbide Cold Heading Dies
Screws Forging Tungsten Carbide Dies , High Strength Carbide Cold Heading Dies
Screws Forging Tungsten Carbide Dies , High Strength Carbide Cold Heading Dies
Screws Forging Tungsten Carbide Dies , High Strength Carbide Cold Heading Dies
Screws Forging Tungsten Carbide Dies , High Strength Carbide Cold Heading Dies
Screws Forging Tungsten Carbide Dies , High Strength Carbide Cold Heading Dies
Screws Forging Tungsten Carbide Dies , High Strength Carbide Cold Heading Dies
Specifications
Brand Name :
Seego Carbide
Model Number :
Tungsten Carbide Cold Forging Dies
Certification :
ISO SGS CE
Place of Origin :
Hunan of China
MOQ :
5 kgs
Price :
USD $38.00~$60.00 / kg
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60 tons/month
Delivery Time :
15~20 days
Packaging Details :
Paper wrapped and hard paper boxes loaded in standard export cartons.
Chemical Composition :
15~25% Cobalt with Medium to Coarse Tungsten Carbide
Product Name :
Tungsten Carbide Cold Forging Dies
Strength :
3200 Mpa
Surface Treatment :
Blanks, Sand Blasted and Fine Grinded
Inner Diameter :
Φ0.5 Φ1.0...Φ50 and Customized Sizes
Product Application :
Screw Caps, Screws Manufacturing
Description

High Strength Tungsten Carbide Cold Forging Dies for Screws Forging

Discriptions:

Tungsten carbide screws forging dies has two definition: cold forging and hot forging.

it used on the cold forging machine, making the materials cutting, reforming, forming to the mould.

we use the advanced HIP sintering technology which makes better density. working life last longer and the punching resistant also improves.

We are manufacturers and suppliers of all types of Carbide Forging Dies.

We produce tungsten carbide die inserts blanks for use in hot and cold forging die tooling and forming tool applications. Inserts are made to order and can be supplied in different tungsten carbide material grades with up to a 25% cobalt binder to meet our customer’s specific requirements to produce bolts, screws and special fixings, in a variety of materials. We produce the die inserts and blanks in the as-sintered condition with the specific overall dimensions and special features our customers request ready for them to produce finished ground tools.

Grades for Tungsten Carbide Forging Dies

GRADE

DENSITY

(g/cm3)

TRS

(N/mm2)

HARDNESS

(HRA)

 Application recommended
YG15 14.0 2800 87.5 For fabricating drawing dies of steel tubes and rods under High compressibility ratio; punching,stamping,forging tools under large stress.
YG20 13.5 3200 85.5 For fabricating of stamping dies for watch parts, spring plates of musical instruments, battery jars, small sized steel balls, screws, screw caps.
YG20C 13.5 3300 83.5 Dies for wear resistant or impact resistant application.
YG22C 13.3 3500 83.0 Nut forming dies and high impact resistance forging dies
YG25C 13.1 3600 82.5 Stainless bolt header dies and rollers.

Specifications:

Punching die blanks for making standard bolts
Type Dimension Range of Applications Type Dimension Range of Applications
d D L d D L
BDP00710- 0.7 10 12.0~20.0 M1 BDP04622- 4.6 22 35.0~60.0 M6
BDP01010- 1 10 12.0~20.0 M1.5~M2 BDP05422- 5.4 22 20.0~60.0 M6
BDP01013- 1 13 15.4-40.0 M1.5~M2 BDP06422- 6.4 22 20.0~60.0 M8
BDP01213- 1.2 13 15.4-40.0 M1.5~M2 BDP06425- 6.4 25 20.0~50.0 M8
BDP01510- 1.5 10 12.0~25.0 M2 BDP06430- 6.4 30 25.0~60.0 M8
BDP01516- 1.5 16 15.0-45.0 M2 BDP07230- 7.2 30 20.0~60.0 M10
BDP01813- 1.8 13 12.0~35.0 M2.5 BDP08230- 8.2 30 20.0~60.0 M10
BDP01816- 1.8 16 20.0-45.0 M2.5 BDP08235- 8.2 35 30.0~60.0 M10
BDP02113- 2.1 13 15.0~30.0 M3 BDP09230- 9.2 30 20.0~60.0 M12
BDP02116- 2.1 16 25.0-45.0 M3 BDP10030- 10 30 20.0~60.0 M12
BDP02316- 2.3 16 15.0-45.0 M3 BDP10035- 10 35 30.0~60.0 M12
BDP02522- 2.5 22 20.0-60.0 M3 BDP11235- 11.2 35 20.0~60.0 M12
BDP02813- 2.8 13 15.0~30.0 M4 BDP11240- 11.2 40 20.0~60.0 M12
BDP02816- 2.8 16 25.0-40.0 M4 BDP11835- 11.8 35 20.0~60.0 M14
BDP02818- 2.8 18 20.0-50.0 M4 BDP11840- 11.8 40 25.0~30.0 M14
BDP02820- 2.8 20 20.0-50.0 M4 BDP13235- 13.2 35 25.0~60.0 M14
BDP02822- 2.8 22 20.0-60.0 M4 BDP13240- 13.2 40 25.0~50.0 M14
BDP02825- 2.8 25 20.0-60.0 M4 BDP13835- 13.8 35 20.0~60.0 M16
BDP03216- 3.2 16 15.0-45.0 M4 BDP13840- 13.8 40 25.0~35.0 M16
BDP03218- 3.2 18 15.0-50.0 M4 BDP14445- 14.4 45 25.0~60.0 M16
BDP03616- 3.6 16 20.0-50.0 M5 BDP15445- 15.4 45 30.0~50.0 M18
BDP03618- 3.6 18 20.0-60.0 M5 BDP16445- 16.4 45 25.0~60.0 M20
BDP03822- 3.8 22 20.0~40.0 M5 BDP17445- 17.4 45 25.0~60.0 M20
BDP03830- 3.8 30 50.0~60.0 M5 BDP19445- 19.4 45 25.0~55.0 M22
BDP04218- 4.2 18 20.0-60.0 M5 BDP21050- 21 50 25.0~55.0 M24
BDP04616- 4.6 16 20.0~30.0 M6 BDP24460- 24.4 60 30.0~50.0 M27

Advantages:


1.Raw material to be choosen strictly, tungsten carbide grain size from medium to coarse.
2.The advanced technology of HIP with low pressure sintering.
3.The HIP sintering makes carbide dies with better density and strength.
4.Special powder pressing technology with HIP sintering, reducing the carbide dies porosity, improve the density and other properties.
5.We would suggest the suitable grade according to customer’s exact applications.

Screws Forging Tungsten Carbide Dies , High Strength Carbide Cold Heading Dies
