Agglomerated YSZ 20% Yttria Stabilized Zirconia Powder For Thermal Spray Coating
Agglomerated YSZ 20% Yttria Stabilized Zirconia Powder For Thermal Spray Coating
Specifications
Brand Name :
BODA
Model Number :
BD-P2122
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
Negotiable
Price :
$42-46/kgs
Payment Terms :
Negotiable
Supply Ability :
10 tons/month
Delivery Time :
7-15days
Packaging Details :
50kg/Steel Drum,25kg/Steel Drum,10kg/Bottle,10 or 20 bottles in a pallets
Classification :
zirconia based
Chemistry :
ZrO2, 20%Y2O3
Manufacture :
Agglomerated.Agglomerated & Plasma Densified
Purpose :
Thermal protection
Particles :
53-20um,100-325mesh
Process :
Atmospheric Plasma Spray,HVOF
Description

YSZ 20 % Yttria Stabilized Zirconia Powders

Chemicals Composition:

YSZ Yttria Stabilized Zirconia Powder For Thermal Spray Coating
Item No Compositon Production Process Application
BD-P2121 Y2O3:8.0%,ZrO2:Balance Agglomerated.Agglomerated & Plasma Densified
 It's widely used in prototype coating and development of advanced thermal barrier coating top coats. Service up to 1350℃(2460℉)
BD-P2122 Y2O3:20.0%,ZrO2:Balance Thermal barrier for turbine hot section components and TBC. Service up to 1500℃(2730℉

Agglomerated YSZ 20% Yttria Stabilized Zirconia Powder For Thermal Spray Coating

Product introduction:

BD-P2122 is zirconium oxide powders stabilized with 20% yttrium oxide (ZrO2-20%Y2O3)

suitable to produce thermal sprayed coatings.

These coatings have better chemical and thermal stability than calcium oxide stabilized zirconium oxide coatings.

Properly applied coating systems using these products are appropriate for applications up to 1500 °C (2730 °F).

It is widely used in high-temperature hot end parts of all kinds of engines to reduce the working temperature of engine matrix and avoid corrosion, wear and high temperature oxidation.

It is mainly used as high-temperature wear-resistant coating material of rocket and engine afterburner, nozzle, roll of continuous casting machine and furnace bottom roller


Boda HVOF Thermal Spray Powder Products ranges:

Product Particle Size Equal to Main Performance Spray Process Applications
WC-10Co-4Cr 45-15um Woka 3651 3652
3653 3654
3655 3665		 Corrosive wear resistance

HVOF,HVAF,

Atmospheric Plasma

 Landing gears
45-11um Paper manufactureing rolls,Corrugating rollers
38-10um Ball,gate and dump valves
25-5um Hydroturbine buckets
WC-12Co 53-20um Woka 3101, Woka 3102, Woka 3103,
Woka 3105,		 Wear resistance

HVOF,HVAF,

Atmospheric Plasma

 Steel rolls
45-15um Corrugating rollers
38-10um Sucker rod couplings
25-5um Conveyor screws
WC-17Co 53-20um Woka 3201 3202
3203 3205 3208		 Ductile Wear resistance

HVOF,HVAF,

Atmospheric Plasma

 Landing gears
45-15um Pump seals
38-10um Exhaust fans
25-5um Crushing rollers
WC-10Ni 53-20um Woka 3301 3302 3303 3304 3305

excellent corrosion resistance,

abrasion and sliding wear

 HVOF,Plasma spray ball valves,gate valves,oil field equipment
45-15um
38-10um radio-active environments
WC-12Ni 45-20um Woka 3402 3403 3404 3406

excellent corrosion resistance,

abrasion and sliding wear

 HVOF,Plasma spray Steeling making
45-15um Centrifugal Casting
38-10um Plastic centrifuge
WC-15Ni 53-20um N/M

excellent corrosion resistance,

abrasion and sliding wear

 HVOF,Plasma spray Steeling making
45-15um Centrifugal Casting
38-10um Plastic centrifuge
WC-20Cr3C-7Ni 53-20um Woka 3701 3702 3702-1 3703 excellent oxidation resistance , good erosion,abrasion wear resistance; HVOF,Plasma spray iron&steel industry, paper making,pump and valve
45-15um field of Screw drilling tools
38-10um chemical equipment in petroleum machinery
25NiCr-Cr3C2 53-20um Woka 7201 7202 7203 7204 7205 7210

Excellent sliding,abrasion,

erosion/Corrosion,wear resistance,

Good cavitation,corrosion resistance.

HVOF,HVAF,

Atmospheric Plasma

 Gas turbine
45-15um aircraft engine,valve rod,powder generation boiler
38-10um metallurgical furnace roller and hydraulic valve etc
20NiCr-Cr3C2 53-20um Woka 7101 7102 7103 7104 7105

Excellent sliding,abrasion,

erosion/Corrisionwear resistance,

Good cavitation,corrosion resistance.

HVOF,HVAF,

Atmospheric Plasma

 Gas turbine
45-15um aircraft engine,valve rod,powder generation boiler
38-10um metallurgical furnace roller and hydraulic valve etc
