Specifications
Brand Name :
Zhenfang
Model Number :
ZF0200
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
1000 pcs
Price :
USD 45-58/kg
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000000 pcs/month
Delivery Time :
3-5 days
Packaging Details :
follow customer requirements
material :
100%virgin tugnsten carbide
surface :
blank or grinding
Application :
cutting tool
Advantage :
High Wear Resistance
grade :
YG6,YG6X,YG8,YG12/YL10.2 etc
Particle :
0.1-0.5um
Description

Blank/ground dia 2mm thin solid 10% cobalt cemented carbide round rod for drilling hole

Product Description

The tungsten carbide rods also can be called cemented carbide rods. They can be in sintered unground condition, high precision grinding and mirror polished. They’re widely used in machining carbon steel, wood, stone, aluminum , non-ferrous metals and titanium, cast iron , stainless steel, etc. The carbide rods are widely used for making PCB drills , drills , cutters, end mills &reamers , mold punches , core pins&hole drilling tools. They also can be used for making of cemented carbide stamping head, core bar and perforation tools, used as wear resistance parts of punching mold,measuring and cutting industry ,etc.

Grade of tungsten carbide rods

Grade Density g/cm³ Hardness HRA TRS (Mpa) Recommended applications and performance
YG6 14.9 89.5 2150 With good wear resistance , suitable for hard wood, prosesisng original wood, bress rods, and cast iron
YG8 14.6 89 2320 Used for the roughening of cast iron and light alloys and also for the milling of cast iron and low-alloy steel.
YL10.2 14.5 92.5 3400 Wear resistance and strength comparatively higher,suitable for processing cast iron, non-ferrous metal

Features:

1. Made from 100% virgin raw material

2. HIP sintering

3. Stable chemical properties

4. High hardness, good compactness

5. Excellent performance and good wear / corrosion resistance

6. Blanks, high machining accuracy / precision

7. Various grades of tungsten carbide available

8. OEM customized sizes available

9. Factory’s offer

10. Strict products quality inspection

Diameter Length

φ0.5-12mm,

Φ12.5-20mm,

Φ21-30mm

Or Based On Requirement

330mm,

330mm,

330mm

Or Based On Requirement

Welcome to contact with us^_^

if you need the customized sizes and grades!

Common size list

Grinding Blank
D L D L
(mm) Tol.(mm) Tol.(+1mm) (mm) Tol.(mm) Tol.(+3mm)
0.7 h6 330 1 +0.2 330
2 h6 330 2.2 +0.2 330
3 h6 330 2.7 +0.2 330
3.175 h6 330 3.2 +0.2 330
4 h6 330 3.7 +0.2 330
5 h6 330 4.2 +0.2 330
6.35 h6 330 4.7 +0.2 330
7 h6 330 5.2 +0.2 330
8 h6 330 5.7 +0.2 330
9 h6 330 6.2 +0.2 330
10 h6 330 6.7 +0.2 330
12 h6 330 7.7 +0.3 330
12.7 h6 330 8.2 +0.3 330
13 h6 330 8.7 +0.3 330
14 h6 330 9.2 +0.3 330
15 h6 330 9.7 +0.3 330
16 h6 330 10.2 +0.3 330
17 h6 330 10.7 +0.3 330
18 h6 330 11.2 +0.3 330
20 h6 330 12.2 +0.3 330
25 h6 330 14.3 +0.3 330
30 h6 330 16.2 +0.3 330

For more size information, please kindly email or call us.For length, we can cut to any size.

Our packing

Based on Detail products, we use different Standard packing suitable overseas shipment.

For carbide rod packing as following

1. outsizde carton or plywood case

2. inner packing is plastic box or small carton with cotton or paper protection
