Specifications
Place of Origin :
Zhuzhou,China
Brand Name :
zhenfang
Certification :
ISO9001:2015
Price :
Negotiable
Packaging Details :
standard packing suitable for overseas shipment: outside carton or plywood case with inner plastic box packing
Delivery Time :
3-15 days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Product Name :
Tungsten carbide bushing
Feature :
Anti corrosion
Application :
Petrochemical industry
Usage :
Water pumps, oil pumps and various other pumps
Description

Good Thermal Wire Guide tungsten carbide grinding wheel round bar

Tungsten Carbide Sleeves &Bushes Description:

Tungsten carbide bush is the basic material among the frictional materials. They are widely use as the basic components for sealing. And the bushings are widely adopted in petrochemical industry due to its excellent performances such as wear ability, anti corrosion.

Tungsten carbide bush is widely known for its durability and quality. It can withstand high pressure and are resistant to corrosion ,so are used in water pumps, oil pumps and various other pumps. Today, tungsten carbide bush has been playing an important role in the field of long working parts material.

Our service:

Having excellent wear resistance, these bushes are available in different sizes and shapes to meet the varied requirements of our clients. The specification we can make is OD 10~ 300, ID 3~ 260 and H 8~ 150 mm. Either blanks or finished products can be provided.

Our material covers:WC-Co alloy, WC-Ni alloy,WC-Ni/Co alloy,WC-Tic-Ni/Cr alloy etc.

Nickel Binder Grades:

Grade Binder(Wt%) Density(g/cm3) Hardness(HRA) TRS(≥N/mm2)
YN6 6 14.7 89.5 1460
YN6X 6 14.8 90.5 1400
YN6A 6 14.8 91.0 1480
YN8 8 14.6 88.5 1710

Cobalt Binder Grades:

Grade Binder(Wt%) Density(g/cm3) Hardness(HRA) TRS(≥N/mm2)
YG6 6 14.8 90 1520
YG6X 6 14.9 91 1450
YG6A 6 14.9 92 1540
YG8 8 14.7 89.5 1750
YG12 12 14.2 88 1810
YG15 15 14.0 87 2050
YG20 20 13.5 85.5 2450

Main Grade for Tungsten carbide wire drawing dies

Grade No.

Density

(g/cm3)

 HRA

T.R.S

(Mpa)

 Application
YG3X 14.9 ≥91.5 ≥1300 For drawing non-ferrous metal wire and stainless steel wire etc.
YG6 14.8 ≥90.0 ≥2150 For drawing steel wire and stainless steel wire etc.
YG6X 14.8 ≥92.0 ≥1860 For drawing nonferrous metal wire, steel wire, stainless steel wire. Good wear resistance and high toughness..
YG8 14.8 ≥89.5 ≥2320 For drawing steel wire, stainless steel wire. Good general performance.
YG11 14.4 ≥88.5 ≥2420 For fabricating drawing dies of steel tubes and rods under high compressibility ratio; punching, stamping, forging tools under large stress.
