Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck
Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck
Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck
Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck
Specifications
Brand Name :
RiXin
Model Number :
Tungsten carbide insert
Certification :
ISO9001:2008; ISO14001:2004
Place of Origin :
Zhuzhou, Hunan, China
MOQ :
1 KG
Price :
USD+49~69+KG
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 tons/month
Delivery Time :
7 to 10 working days depending on the order quantity and requirements
Packaging Details :
paper, then paper boxes, then exported wooden cartons or paper cases,or packed as customers'requirement.
Product name :
Cemented Tungsten Carbide Jaw Chuck Gripper Pads, carbide gripper insert
Material :
Tungsten carbide, cemented carbide, widia
Grade :
YG6, YG8, YK05, MR06H, YG8C, ZD15, YG9C, YG10C, YG11C, YG13C, YG15C, YG15
Surface :
ground, sintered blasting, nickel coating, tumble finishing
Hardness :
HRA 85-90.5
Keywords :
carbide insert, gripper, jaw insert, chuck jaw, gripper pad
Size :
customized or standard
Sample :
acceptable
Application :
gripper, chuck jaw
Description

Cemented Tungsten Carbide Jaw Chuck Gripper Pads, carbide gripper insert

Tungsten Carbide gripper inserts are suitable for hard rock ,coal mining,diamond drilling,stone mining and oil mining.

Tungsten Carbide gripper inserts are used in different ways, such as diamond drilling, coal mining, stone mining and oil mining.
Carbide Inserts for Hydraulic and Mechanical chucks
Tungsten Carbide Gripper Insert Gripper Teeth

Description


Item Tungsten carbide gripper insert
Grade YG6, YG8, YK05, 06H, YG8C, ZD15, YG9C, YG10C, YG11C, YG13C, YG15C, YG15.
Sizes 22x9.5x6, other sizes can be customized
Brand Rixin
Country of Origin Zhuzhou, China
Usage stone cutting

Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck

Grades:

Grades

Density

g/cm³

T.R.S

Mp α

Hardness

HRA

 Performance &application recommended Approx grades in China ISO Grade
MK4 15.1 1800 90.0 Mainly used as small buttons for percussion bits to cut soft and medium hard formations. YG4C K01-K05
MK6 14.9 2100 90.5 For coring crowns, electric coal drill bits, coal cutting picks, oil cone bits and scraping knife bits, used in geological prospecting, coal mining and oil well boring. YG6 K10
MR06H 14.94 3000 90.5 Good strength and wear resistance, for bits of rotary hammer rock drills and heavy rock drills, for hard and very hard rocks. YK05,KK06H K10
MK8 14.7 2800 89.8 For coring crowns, electric coal drill bits, coal cutting picks, oil cone bits and scraping knife bits, used in geological prospecting, coal mining and oil well boring. YG8 K20
MK10 14.7 2700 89 Mostly used as the buttons of small and medium sized percussion bits and as the inserts of rotary prospecting bits to cut soft and medium hard formations.

YG8C

ZD15

 K20
MK15 14.6 2750 88 Suitable for strips, conical buttons for rotary percussion drill bits, geological prospecting buttons, cut soft and medium hard formations.

YK15

YG9C

 K20-K30
MK20 14.5 2800 87.5 Primarily for the buttons and inserts of rotary percussion bits to cut medium-hard and hard formations.

YK20

YG10C

 K30
MK30 14.4 2850 87.0 Largely used for the inserts and buttons of percussion bits and tricone bits to cut medium-hard, hard and very hard formations. YG11C K20-K30
MK40 14.2 2900 86 Mainly used for the buttons of tricone bits, and inserts of rotary percussion bits to cut hard and very hard formations.

YK40

YG13C

 K40
MK50 14.0 3000 85 For oil cone drill bits, for medium soft and medium-hard rocks. YG15C K40
MK60 14.0 3000 87 Good strength and less wear resistance, for bits of rotary hammer rock drills and heavy rock drills, for hard and very hard rocks. YG15 K40

Other grades can be supplied according to customers’ requirements.

Types:


Other types can be supplied according to customers’ requirements.

Application:

Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck

Package:

Packing Paper+paper boxes+exported wooden cartons or paper cases.
As a manufacturer, Mingri can provide any kinds of package as buyer's requirement.
Shipping UPS,TNT,EMS,Fedex,DHL,or as you request.
Delivery 7-10 days after confirm all details.

Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck

Main products:

We are specialized in all kinds of tungsten carbide profiles and dies, cutting tools, mining tools, wear parts and all kinds of non-standard customized tool parts with high performance in the industry.

For details about the below products, please click the More on below pictures:

Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck
Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck
Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck Carbide Gripper Pads Carbide Gripper Inserts Cemented Tungsten Carbide Jaw Chuck
