Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold
Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold
Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold
Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold
Specifications
Brand Name :
JWE
Model Number :
YG12C/YL2/YG9D
Certification :
ISO9001
Place of Origin :
China
MOQ :
5 Kilograms
Price :
Negotiable
Payment Terms :
D/P, T/T, Western Union
Supply Ability :
1000 Tons per year
Delivery Time :
10-15 work days
Packaging Details :
41cm*20cm*12cm
Material :
100% Virgin Tungsten Carbide
Grade :
YG6/YG8
Size :
Customized
Shipment :
As your Request
Warranty :
More than 5 years
Color :
black alloy
Usage :
Metal wire drawinng
Chemical composition :
Co-WC
Description
Production Description

Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading:Tungsten carbide die used for cold heading and cold punching standard parts, bearings, screws, and nuts. With high impact resistance, toughness, and wear resistance. Wire drawing dies are commonly used to reduce the diameter of various ferrous and non-ferrous rods and wires. Applications include various grades of the low, medium, and high carbon steels, steel alloys, stainless steel, welding wire as well as various non-ferrous rods and wires.

Features:

Tungsten carbide cold heading dies for fasteners, high impact resistance, toughness, wear resistance, and quality consistency. You are encouraged to use our professional carbide grades for cold heading &punching die nibs. Power metallurgical Compacting dies and other industries.For stable performance and high-cost-effectiveness.They have been proved to be ideal in making non-ferrous metal, ferrous metal, and their alloys.
Different grades with different properties and applications. Of course, the price will be different, When purchasing, Pls first choose the grade.

Grades and Properties

Grade Density(g/cm3) Hardness(HRA) TRS(MPa)
YG6X 14.95 91.5 1800
YG6 14.95 90.5 1900
YG8 14.8 89.5 2200
YG10 14.5 88.5 2400
YG15 14.0 87.0 2800

Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold

Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold

Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold

Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold

Performance Chart

Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold

Product Packaging

Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold

Company Introduction

JWE Carbide Co., Ltd. is designated as a high-tech and new material enterprise, was founded in March of 2005, with registered capital USD1, 000, 000, located in Lukou Economic Zone of Zhuzhou city, the hometown of Chinese Tungsten Carbide. Our factory covers an area of 20,000 square meters, equipped with advanced technologies and manufacturing equipment, we major in researching, developing and producing medium and high grade tungsten carbide products.
Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold
Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold
Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold
Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold
Tungsten Carbide Dies 2400MPa Bar Drawing Dies Cold Heading and Mold
