Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Specifications
Brand Name :
JWE
Model Number :
JK30.4/JK20.8
Certification :
ISO9001:2015
Place of Origin :
MADE IN CHINA
MOQ :
10 Kilograms
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A
Supply Ability :
1000T/ year
Delivery Time :
10-20 days
Packaging Details :
41cm*20cm*12cm OR CUSTOMIZED
Material :
100% Virgin Tungsten Carbide + Cobalt
Hardness :
85.0-90.5HRA
TRS :
2450- 2800 mPa
Package :
Cartons
Process :
HIP sintered
Treatment :
Sand blasting
Application :
Coal Mining, Drilling in Quarry, Tunneling Trenching
Service :
OEM/ODM
Types :
Conical/ Biconical
Description

Tungsten Carbide Conical Biconical Buttons Tooth In Application Of Bits On Mining, Construciton Sites, Oilfield

Tungsten Carbide Inserts, Buttons, and Teeth:
Tungsten carbide inserts, buttons, teeth are importance industrial consumption working parts for drilling bits.
They are made of super hardness carbide and is widely used for drilling operation in surface and underground
mining, boring in quarries, drilling water well efficiently and economically. They are easy to assembly and replace,
and have extensive application domains.
The tungsten Carbide inserts, buttons, tips we offered are using for borehole drilling,
road plaining, tunnel excavation, well digging, coal mining, oilfield application, civil constructions, etc.
The tungsten carbides are stable in mechanical properties, easy in soldering, with high wear resistance
and high impact resistance. A carbide drill bit will last up to 25 times longer than a common steel bit.

The Properties of the Grade:

Grade

Density

Density

Hardness

Hardness

TRS(mPA)

JK30.4

14.45

14.60

85.0

86.5

2600

JK25.8

14.55

14.70

85.0

86.5

2800

JK10.2

14.86

14.50

89.5

90.5

2450


Products in Blanks:

Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield

Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield

Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield

Finished Products:

Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield

Applications:

For drilling tool bits of mining and rock drilling machine, and excavation carbide conical shape button tips for mining and oil-field.

Supply Ability:
The annual output capacity is reached 1000 ton under the normal operation.
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield

Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield



Package & Delivery:
A:Package: Plastic bags + Cartons / Pallet
B:Transportation: By air transportation, railway, sea transportation.
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield
Conical Biconical Tungsten Carbide Buttons for Mining Construciton Sites Oilfield

FAQ:

Q: Are you a trading company or a manufacturer?
A: We are a professional factory, with more than 16 years in manufacturing tungsten carbide products.
Q: How to send an inquiry?
A: It's better to send us detailed specifications and photos of products, as well as the detailed info for application.
Q: How do you guarantee your quality?
A:Firstly, we do a quality test during every process. Secondly, we will collect all comments on our products from customers in time. And try our best to improve quality all the time.
Q: Do you offer samples?
A: Yes, we do offer samples. However, buyers need to pay for the freight charge. In addition, whether samples are free or not depends on the quantity you buy.
Q: What kinds of payment do you accept?
A: In addition to the patterns of payment shown above, you can discuss with us in which way you would like to pay.
